Sharp XV-Z12000 Service Manual

183
XV-Z12000
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
R9208 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R9209 VRS-CY1JF111FY J 110 1/16W Metal Oxide AA
R9210 VRS-CY1JF330FY J 33 1/16W Metal Oxide AA
R9211 VRS-CY1JF121FY J 120 1/16W Metal Oxide AA
R9212 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R9213 VRS-CY1JF390FY J 39 1/16W Metal Oxide AA
R9214 VRS-CY1JF390FY J 39 1/16W Metal Oxide AA
R9215 VRS-CY1JF390FY J 39 1/16W Metal Oxide AA
R9216 VRK-CD1JJ390FY J 39 1/16W AC
Metal Composition
R9217 VRK-CD1JJ390FY J 39 1/16W AC
Metal Composition
R9218 VRK-CD1JJ390FY J 39 1/16W AC
Metal Composition
R9219 VRS-CY1JF390FY J 39 1/16W Metal Oxide AA
R9301 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R9302 VRS-CY1JF000JY J 00 1/16W Metal Oxide AA
R9304 VRS-CF1JP100JY J 10 1/16W Metal Oxide AC
R9305 VRS-CF1JP100JY J 10 1/16W Metal Oxide AC
R9306 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R9307 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R9308 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R9309 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R9401 RR-SZ0090CEZZY J 2.74k Acid Metal AA
R9402 RR-SZ0089CEZZY J 2.26k Acid Metal AA
R9403 VRS-CY1JF154JY J 150k 1/16W Metal Oxide AA
R9404 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide AA
R9405 VRS-TV1JD301JY J 300 1/16W Metal Oxide AA
R9406 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide AA
R9407 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide AA
R9408 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide AA
R9409 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide AA
R9410 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R9411 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R9412 VRS-CY1JF152JY J 1.5k 1/16W Metal Oxide AA
R9413 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R9414 VRS-CY1JF302JY J 3k 1/16W Metal Oxide AA
R9415 VRS-TQ2BD101JY J 100 1/8W Metal Oxide AA
R9416 VRS-CY1JF106JY J 10M 1/16W Metal Oxide AA
R9417 VRS-CY1JF106JY J 10M 1/16W Metal Oxide AA
R9418 VRS-TQ2BD101JY J 100 1/8W Metal Oxide AA
R9419 VRS-CY1JF106JY J 10M 1/16W Metal Oxide AA
R9420 VRS-TQ2BD101JY J 100 1/8W Metal Oxide AA
R9421 VRS-TW2HPR39JY J 0.39 1/2W Metal Oxide AB
R9422 VRS-TW2HPR39JY J 0.39 1/2W Metal Oxide AB
R9423 VRS-TW2HPR39JY J 0.39 1/2W Metal Oxide AB
R9424 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R9501 VRS-CY1JF330FY J 33 1/16W Metal Oxide AA
R9502 VRS-CY1JF000JY J 00 1/16W Metal Oxide AA
R9907 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R9912 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
FB9002 RBLN-0253TAZZY J Ferrite Bead AA
FB9103 RBLN-0253TAZZY J Ferrite Bead AA
FB9104 RBLN-0253TAZZY J Ferrite Bead AA
FB9201 RBLN-0253TAZZY J Ferrite Bead AA
FB9301 RBLN-0253TAZZY J Ferrite Bead AA
FB9003 RBLN-0209TAZZY J Ferrite Bead AB
FB9101 RBLN-0209TAZZY J Ferrite Bead AB
FB9102 RBLN-0209TAZZY J Ferrite Bead AB
FB9401 RBLN-A009WJZZY J Ferrite Bead AB
FB9501 RBLN-A009WJZZY J Ferrite Bead AB
FB9502 RBLN-A009WJZZY J Ferrite Bead AB
FB9402 RBLN-A007WJZZY J Ferrite Bead AC
FB9403 RBLN-A007WJZZY J Ferrite Bead AC
FB9404 RBLN-A007WJZZY J Ferrite Bead AC
P9001 QPLGN0588FJZZY J Plug, 30pin AH
P9003 QPLGN0182FJZZY J Plug, 10pin AD
P9401 QPLGN0463TAZZY J Plug, 4pin AC
P9402 QPLGNA038WJZZY J Plug, 4pin AD
SC9002 QSOCN0687FJZZY J Socket AF
S9101 QSW-S0203TAZZY J Slide Switch AD
S9102 QSW-S0203TAZZY J Slide Switch AD
C9542 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9543 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9544 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9545 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9546 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9547 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9548 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9549 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9550 VCKYCY1AB105KY J 1 10V Ceramic AB
C9551 VCKYCY1AB105KY J 1 10V Ceramic AB
RESISTORS
R9002 VRS-CY1JF132JY J 1.3k 1/16W Metal Oxide AG
R9003 VRS-CY1JF132JY J 1.3k 1/16W Metal Oxide AG
R9004 VRS-CY1JF132JY J 1.3k 1/16W Metal Oxide AG
R9005 VRS-CY1JF132JY J 1.3k 1/16W Metal Oxide AG
R9016 VRS-CY1JF000JY J 00 1/16W Metal Oxide AA
R9041 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R9045 VRS-CF1JP330JY J 33 1/16W Metal Oxide AC
R9046 VRS-CF1JP330JY J 33 1/16W Metal Oxide AC
R9047 VRS-CF1JP330JY J 33 1/16W Metal Oxide AC
R9048 VRS-CF1JP330JY J 33 1/16W Metal Oxide AC
R9050 VRS-CY1JF000JY J 00 1/16W Metal Oxide AA
R9054 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R9055 VRN-CY1JF202DY J 2k 1/16W Metal Film AA
R9056 VRN-CY1JF470DY J 47 1/16W Metal Film AA
R9057 VRN-CY1JF202DY J 2k 1/16W Metal Film AA
R9059 VRS-CY1JF330FY J 33 1/16W Metal Oxide AA
R9060 VRS-CY1JF330FY J 33 1/16W Metal Oxide AA
R9061 VRS-CY1JF132JY J 1.3k 1/16W Metal Oxide AG
R9062 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R9063 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R9064 VRN-CY1JF822DY J 8.2k 1/16W Metal Film AA
R9065 VRN-CY1JF103DY J 10k 1/16W Metal Film AA
R9066 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R9067 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R9101 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R9102 VRS-CF1JP102JY J 1k 1/16W Metal Oxide AC
R9103 VRS-CF1JP102JY J 1k 1/16W Metal Oxide AC
R9104 VRS-CY1JF220FY J 22 1/16W Metal Oxide AA
R9105 VRS-CY1JF220FY J 22 1/16W Metal Oxide AA
R9106 VRS-CY1JF220FY J 22 1/16W Metal Oxide AA
R9107 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R9108 VRS-CY1JF220FY J 22 1/16W Metal Oxide AA
R9110 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R9112 VRS-CY1JF390FY J 39 1/16W Metal Oxide AA
R9113 VRS-CF1JP102JY J 1k 1/16W Metal Oxide AC
R9114 VRS-CY1JF000JY J 00 1/16W Metal Oxide AA
R9115 VRS-CF1JP102JY J 1k 1/16W Metal Oxide AC
R9116 VRS-CY1JF000JY J 00 1/16W Metal Oxide AA
R9117 VRS-CY1JF000JY J 00 1/16W Metal Oxide AA
R9118 VRS-CF1JP102JY J 1k 1/16W Metal Oxide AC
R9119 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R9120 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R9121 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R9122 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R9123 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R9124 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R9128 VRS-CY1JF132JY J 1.3k 1/16W Metal Oxide AG
R9129 VRS-CY1JF330FY J 33 1/16W Metal Oxide AA
R9132 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R9133 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R9135 VRS-CY1JF330FY J 33 1/16W Metal Oxide AA
R9138 VRS-CY1JF132JY J 1.3k 1/16W Metal Oxide AG
R9139 VRS-CY1JF330FY J 33 1/16W Metal Oxide AA
R9140 VRS-CY1JF330FY J 33 1/16W Metal Oxide AA
R9201 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R9203 VRS-CY1JF560FY J 56 1/16W Metal Oxide AA
R9204 VRS-CY1JF111FY J 110 1/16W Metal Oxide AA
R9205 VRS-CY1JF111FY J 110 1/16W Metal Oxide AA
R9206 VRS-CY1JF560FY J 56 1/16W Metal Oxide AA
R9207 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
DUNTKB474FE03
FORMATTER UNIT(Continued)
