Sharp XV-Z12000 Service Manual

184
XV-Z12000
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
RDENCA055WJZZ
POWER UNIT
INTEGRATED CIRCUITS
å IC7001 95CH1101AC001 J FA5332M BD
IC7002 95C0H1Q3A0010 J TA76431 AQ
IC7151 95C0H1Q3A0010 J TA76431 AQ
å IC7201 95C0H132A0010 J AN8021L AV
IC7301 95C0H1Q3A0010 J TA76431 AQ
IC7351 95C0H146A0010 J PQ1CG21H2FZ AW
IC7401 95C0H141A0010 J HA16114P AY
TRANSISTORS
Q7001 95C0T252A0010 J 2SB1237 AM
Q7002 95C0T454A0010 J 2SD1858 AM
Q7003 95C0T196A0010 J 2SA1812 AS
Q7004 95C0T643A0010 J FET, 2SK2698 AY
Q7005 95C0T643A0010 J FET, 2SK2698 AY
Q7006 95C0T394A0010 J 2SC4081 AH
Q7007 95C0T192A0010 J 2SA1576A AH
Q7101 95C0T395A0020 J 2SC4097 AL
Q7102 95C0T645A0020 J FET, 2SK2717 AW
Q7103 95C0T193A0010 J 2SA1577 AK
Q7104 95C0T394A0010 J 2SC4081 AH
Q7105 95C0T192A0010 J 2SA1576A AH
Q7106 95C0T394A0010 J 2SC4081 AH
Q7107 95C0T394A0010 J 2SC4081 AH
Q7151 95C0T397A0010 J 2SC4672K AM
Q7201 95C0T640A0010 J FET, 2SK2651-01MR AV
Q7202 95C0T192A0010 J 2SA1576A AH
Q7401 95C0T502A0010 J FET, 2SJ303 AT
Q7402 95C0T394A0010 J 2SC4081 AH
Q7403 95C0T394A0010 J 2SC4081 AH
DIODES
å D7001 95C0D118A0060 J D15XB60 AX
å D7002 95C0D157A0060 J ERA15-06 AE
å D7003 95C0D157A0060 J ERA15-06 AE
å D7004 95C0D157A0060 J ERA15-06 AE
å D7005 95C0D157A0060 J ERA15-06 AE
å D7006 95C0D157A0060 J ERA15-06 AE
å D7007 95C0D157A0060 J ERA15-06 AE
D7010 95CD2172AL006 J SF10L60U AR
D7012 95C0D491A0290 J Zener Diode, UDZ 30B AM
D7013 95C0D491A0290 J Zener Diode, UDZ 30B AM
D7014 95C0D491A0290 J Zener Diode, UDZ 30B AM
D7015 95C0D264A0020 J ERB44-02 AG
D7101 95C0D491A0080 J Zener Diode, UDZ 3.9B AL
D7102 95C0D295A0080 J 1SS355 AE
D7103 95C0D295A0080 J 1SS355 AE
D7104 95C0D491A0190 J Zener Diode, UDZ 11B AL
D7105 95C0D295A0080 J 1SS355 AE
D7109 95C0D295A0080 J 1SS355 AE
D7111 95C0D492A0070 J Zener Diode, UDZ S 9.1B AK
D7112 95C0D492A0020 J Zener Diode, UDZS 5.6B AK
D7113 95C0D295A0080 J 1SS355 AE
D7114 95C0D491A0190 J Zener Diode, UDZ 11B AL
D7115 95C0D292A0020 J SC902-2 AM
D7151 95C0D271A0020 J ERA92-02 AM
D7152 95C0D265A0020 J ERA91-02 AL
D7201 95C0D265A0020 J ERA91-02 AL
D7202 95C0D267A0100 J ERA22-10 AM
D7203 95C0D491A0290 J Zener Diode, UDZ 30B AM
D7204 95C0D491A0290 J Zener Diode, UDZ 30B AM
D7206 95C0D264A0020 J ERB44-02 AG
D7207 95C0D491A0050 J Zener Diode, UDZ 3.0B AF
D7301 95C0D222B0020 J YG902C2R AQ
D7302 95C0D491A0290 J Zener Diode, UDZ 16B AM
D7303 95C0D295A0080 J 1SS355 AE
D7351 95C0D295A0080 J 1SS355 AE
D7352 95C0D219B0060 J YG811S06R AM
D7401 95C0D227B0040 J YG805C04R AT
D7402 95C0D227B0040 J YG805C04R AT
D7404 95C0D492A0050 J Zener Diode, UDZ S7.5B AK
D7405 95C0D295A0080 J 1SS355 AE
PACKAGED CIRCUITS
å PC7101 95CH7101AS002 J Optical Isolator, AN
SFH615AGR-X016
å PC7201 95CH7101AS002 J Optical Isolator, AN
SFH615AGR-X016
å PC7202 95CH7101AS002 J Optical Isolator, AN
SFH615AGR-X016
å TRA7001 95C0D513A6120 J Triode AC Semiconductor AT
Switch, SM12JZ47
å Z7001 95C0D754A4710 J Transient Voltage Surge AL
Suppressor, ENC471
PTC7001 95C0D802A1010 J Posistir, AP
PTH9M04BD222TS2F333
COILS AND TRANSFORMER
å L7001 95C0L107R8020 J Inductor, FK-080G-8020R AX
å L7002 95C0L107R8020 J Inductor, FK-080G-8020R AX
å L7005 95C0L110K2230 J Inductor, PLA10A2230R4D02B1 AR
L7006 95C0L114R1010 J Inductor, SK-12M-5YRP AT
L7007 95C0L106R1020 J Inductor, HK-14D100-1020 BB
L7351 95C0L150S1000 J Inductor, 10µHAN
L7352 95C0L124R1310 J Inductor, HK-08S060-1310 AT
L7401 95C0L124R3000 J Inductor, HK-08S080-3000R AR
å T7001 95CL2000BS023 J Transformer, 2BS23 AX
å T7002 95CL2000US075 J Transformer, 2US75 BA
CAPACITORS
å C7001 95C0C245Q4740 J 0.47 AC250V Film AS
å C7002 95C0C1H8Q4710 J 470p AC250V Ceramic AG
å C7004 95C0C1H8Q4720 J 4700p AC250V Ceramic AN
å C7005 95C0C1H8Q4710 J 470p AC250V Ceramic AG
å C7006 95C0C245Q2240 J 0.22 AC250V Film AL
C7008 95C0C1Q2B1040 J 0.1 16V Ceramic AH
C7009 95C0C247M4740 J 0.47 450V Film AV
C7010 95C0C377M1R00 J 1 400V Eleectrolytic AM
C7011 95C0C1Q1E4710 J 470p 50V Ceramic AH
C7012 95C0C1Q1E1010 J 100p 50V Ceramic AH
C7013 95C0C1Q2E1030 J 0.01 50V Ceramic AH
C7014 95C0C1Q1E3310 J 330p 50V Ceramic AH
C7015 95C0C247M4740 J 0.47 450V Film AV
C7016 95C0C1Q2B1040 J 0.1 16V Ceramic AH
C7017 95C0C195C1040 J 0.1 25V Ceramic AD
C7020 95C0C1A9R2210 J 220p 1kV Ceramic AF
C7022 95CC3124ML181 J 180 400V Eleectrolytic AC
C7023 95C0C364E4R70 J 4.7 50V Eleectrolytic AL
C7024 95C0C374D8200 J 82 35V Eleectrolytic AL
å C7026 95C0C245Q2240 J 0.22 AC250V Film AL
C7027 95C0C195C1040 J 0.1 25V Ceramic AD
C7028 95C0C1Q2B1040 J 0.1 16V Ceramic AH
å C7101 95C0C1H8Q4710 J 470p AC250V Ceramic AG
C7102 95C0C366MR3R3 J 3.3 400V Eleectrolytic AP
C7104 95C0C1Q2E4720 J 4700p 50V Ceramic AH
C7105 95C0C194E1020 J 1000p 50V Ceramic AK
C7106 95C0C1Q1E1010 J 100p 50V Ceramic AH
C7108 95C0C195E1040 J 0.1 50V Ceramic AF
C7109 95C0C1Q2E1030 J 0.01 50V Ceramic AH
C7110 95C0C1Q2E1030 J 0.01 50V Ceramic AH
C7111 95C0C1Q2E1030 J 0.01 50V Ceramic AH
C7112 95C0C195E1040 J 0.1 50V Ceramic AF
C7151 95C0C375B4710 J 470 16V Eleectrolytic AN
C7152 95C0C195E1040 J 0.1 50V Ceramic AF
C7201 95CC3124ML181 J 180 400V Eleectrolytic AX
C7202 95C0C157R1010 J 100p 1kV Ceramic AK
C7203 95C0C1A9R1020 J 1000p 1kV Ceramic AK
C7205 95C0C1Q2E1030 J 0.01 50V Ceramic AH
C7206 95C0C195C1040 J 0.1 25V Ceramic AD
C7207 95C0C1Q2E1030 J 0.01 50V Ceramic AH
C7208 95C0C3A0D3300 J 33 35V Eleectrolytic AK
C7209 95C0C1Q1E4710 J 470p 50V Ceramic AH
C7210 95C0C1Q2E1030 J 0.01 50V Ceramic AH
C7211 95C0C1Q2C4730 J 0.047 25V Ceramic AH
C7213 95C0C1Q2E1030 J 0.01 50V Ceramic AH
C7216 95C0C195B4740 J 0.47 16V Ceramic AD
