Sharp XV-Z12000 Service Manual

185
XV-Z12000
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
RDENCA055WJZZ
POWER UNIT(Continued)
C7301 95C0C1A9R2210 J 220p 1kV Ceramic AF
C7302 95C0C3A0C8210 J 820 25V Eleectrolytic AQ
C7303 95C0C3A0C8210 J 820 25V Eleectrolytic AQ
C7304 95C0C364E1R00 J 1 50V Eleectrolytic AL
C7351 95C0C374D5610 J 560 35V Eleectrolytic AP
C7352 95C0C1Q2B1040 J 0.1 16V Ceramic AH
C7353 95C0C374D5610 J 560 35V Eleectrolytic AP
C7354 95C0C1Q2B1040 J 0.1 16V Ceramic AH
C7401 95C0C3A0B1020 J 1000 16V Eleectrolytic AQ
C7402 95C0C3A0B1020 J 1000 16V Eleectrolytic AQ
C7404 95C0C374A1020 J 1000 10V Eleectrolytic AN
C7405 95C0C374A1020 J 1000 10V Eleectrolytic AN
C7406 95C0C195C1040 J 0.1 25V Ceramic AD
C7407 95C0C195C1040 J 0.1 25V Ceramic AD
C7408 95C0C364E4R70 J 4.7 50V Eleectrolytic AL
C7409 95C0C1Q2E1030 J 0.01 50V Ceramic AH
C7410 95C0C1Q2E1020 J 1000p 50V Ceramic AH
C7411 95C0C1Q1E2210 J 220p 50V Ceramic AH
C7412 95C0C1Q2E3320 J 3300p 50V Ceramic AH
C7413 95C0C1Q2B1040 J 0.1 16V Ceramic AH
C7417 95C0C1A9R2210 J 220p 1kV Ceramic AF
C7428 95C0C374C1210 J 120 25V Eleectrolytic AL
å C7430 95C0C1H8Q1020 J 1000p
AC250V Ceramic AH
å C7431 95C0C1H8Q1020 J 1000p AC250V Ceramic AH
å C7432 95C0C1H8Q4710 J 470p AC250V Ceramic AG
å C7433 95C0C1H8Q4710 J 470p AC250V Ceramic AG
RESISTORS
R7106 95C0R3Q4S0000 J 0 1/16W AC
å R7001 95C0R105C2740 J 270k 1W AF
R7002 95C0R390T1000 J 10 1/4W AC
R7003 95C0R390T1000 J 10 1/4W AC
R7004 95C0R3Q4S1020 J 1k 1/16W Chip1608 AH
R7005 95CR5022FQ4R7 J 4.7 5W AP
R7006 95CR5015GQ4R7 J 4.7 5W AB
R7007 95C0R391T1840 J 180k 1/4W AC
R7008 95C0R451C1000 J 10 1W AD
R7009 95C0R3Q8S2720 J 2.7k 1/16W Chip1608 AH
R7010 95C0R3Q4S1030 J 10k 1/16W Chip1608 AH
R7012 95C0R3Q8S3930 J 39k 1/16W Chip1608 AH
R7013 95C0R3Q4S1000 J 10 1/16W Chip1608 AH
R7014 95C0R391T1840 J 180k 1/4W AC
R7015 95C0R391T1840 J 180k 1/4W AC
R7016 95C0R3Q4S2740 J 270k 1/16W Chip1608 AH
R7017 95C0R3Q4S3340 J 330k 1/16W Chip1608 AH
R7018 95C0R390T2200 J 22 1/4W Chip3216 AH
R7019 95C0R390T4700 J 47 1/4W Chip3216 AH
R7020 95C0R3Q4S3330 J 33k 1/16W Chip1608 AH
R7021 95C0R390T1000 J 10 1/4W AC
R7022 95C0R516FR100 J 0.1 3W AN
R7023 95C0R516FR100 J 0.1 3W AN
R7025 95C0R362U1500 J 15 1/6W Fuse Resistor AK
R7026 95C0R362U1500 J 15 1/6W Fuse Resistor AK
R7029 95C0R391T2240 J 220k 1/4W AH
R7031 95C0R3Q4S1030 J 10k 1/16W Chip1608 AH
R7032 95C0R3Q4S1030 J 10k 1/16W Chip1608 AH
R7034 95C0R3Q4S1010 J 100 1/16W Chip1608 AH
R7035 95C0R3Q8S2720 J 2.7k 1/16W Chip1608 AH
R7036 95C0R3Q8S1010 J 100 1/16W AC
R7037 95C0R3Q8S2220 J 2.2k 1/16W Chip1608 AH
R7038 95C0R3Q4S1030 J 10k 1/16W Chip1608 AH
R7039 95C0R3Q4S3320 J 3.3k 1/16W Chip1608 AH
R7040 95C0R391T2240 J 220k 1/4W AH
R7041 95C0R391T2240 J 220k 1/4W AH
R7042 95C0R391T1840 J 180k 1/4W AC
R7043 95C0R391T1840 J 180k 1/4W AC
R7044 95C0R3Q4S1030 J 10k 1/16W Chip1608 AH
R7045 95C0R3Q4S2740 J 270k 1/16W Chip1608 AH
R7046 95C0R3Q4S2740 J 270k 1/16W Chip1608 AH
R7047 95C0R3Q8S1330 J 13k 1/16W AH
R7048 95C0R391T1840 J 180k 1/4W AC
R7049 95C0R3Q4S2220 J 2.2k 1/16W Chip1608 AH
R7050 95C0R391T4740 J 470k 1/4W Chip3216 AH
R7051 95C0R391T4740 J 470k 1/4W Chip3216 AH
R7052 95C0R3Q0V2730 J 27k 1/8W Chip2012 AH
R7053 95C0R390T5620 J 5.6k 1/4W Chip3216 AC
R7054 95C0R390T3340 J 330k 1/4W Chip3216 AC
R7055 95C0R390T3340 J 330k 1/4W Chip3216 AC
R7056 95C0R390T3340 J 330k 1/4W Chip3216 AC
R7057 95C0R391T4740 J 470k 1/4W Chip3216 AH
R7061 95C0R451C1000 J 10 1W AD
R7101 95C0R3Q4S2240 J 220k 1/16W Chip1608 AH
R7102 95C0R3Q4S2710 J 270 1/16W Chip1608 AH
R7103 95C0R3Q4S3330 J 33k 1/16W Chip1608 AH
R7104 95C0R3Q4S6810 J 680 1/16W Chip1608 AH
R7105 95C0R3Q4S8220 J 8.2k 1/16W Chip1608 AH
R7107 95C0R3Q4S2230 J 22k 1/16W AH
R7108 95C0R3Q4S4730 J 47k 1/16W Chip1608 AH
R7110 95C0R3Q8S2740 J 270k 1/16W AC
R7112 95C0R3Q4S1040 J 100k 1/16W Chip1608 AH
R7113 95C0R390T3340 J 330k 1/4W Chip3216 AC
R7114 95C0R390T2740 J 270k 1/4W Chip3216 AC
R7115 95C0R3Q4S6820 J 6.8k 1/16W Chip1608 AH
R7116 95C0R3Q4S6830 J 68k 1/16W Chip1608 AH
R7117 95C0R3Q4S1030 J 10k 1/16W Chip1608 AH
R7118 95C0R3Q4S2240 J 220k 1/16W Chip1608 AH
R7119 95C0R3Q4S4730 J 47k 1/16W Chip1608 AH
R7120 95C0R3Q0V4730 J 47k 1/16W AH
R7121 95C0R390T3340 J 330k 1/4W Chip3216 AC
R7123 95C0R3Q4S1030 J 10k 1/16W Chip1608 AH
R7124 95C0R3Q4S1010 J 100 1/16W Chip1608 AH
R7125 95C0R3Q4S1030 J 10k 1/16W Chip1608 AH
R7126 95C0R3Q4S1040 J 100k 1/16W Chip1608 AH
R7127 95C0R3Q4S1000 J 10 1/16W Chip1608 AH
R7151 95C0R3Q4S8210 J 820 1/16W Chip1608 AH
R7152 95C0R3Q4S5610 J 560 1/16W Chip1608 AH
R7153 95C0R3Q4S6820 J 6.8k 1/16W Chip1608 AH
R7154 95C0R3Q4S5610 J 560 1/16W Chip1608 AH
R7155 95C0R3Q8S2720 J 2.7k 1/16W Chip1608 AH
R7156 95C0R3Q4S1030 J 10k 1/16W Chip1608 AH
R7157 95C0R3Q4S1020 J 1k 1/16W Chip1608 AH
R7158 95C0R3Q4S6800 J 68 1/16W Chip1608 AH
R7159 95C0R3Q8S2220 J 2.2k 1/16W Chip1608 AH
R7201 95C0R390T1500 J 15 1/4W AH
R7207 95C0R452D3930 J 39k 2W AK
R7208 95C0R452D3930 J 39k 2W AK
R7209 95C0R516FR220 J 0.22 3W AR
R7210 95C0R390T1000 J 10 1/4W AC
R7211 95C0R3Q4S1030 J 10k 1/16W Chip1608 AH
R7212 95C0R3Q4S1040 J 100k 1/16W Chip1608 AH
R7213 95C0R3Q4S1030 J 10k 1/16W Chip1608 AH
R7215 95C0R3Q4S1030 J 10k 1/16W Chip1608 AH
R7217 95C0R3Q4S1810 J 180 1/16W AB
R7218 95C0R3Q8S1830 J 18k 1/16W Chip1608 AH
R7219 95C0R3Q4S1020 J 1k 1/16W Chip1608 AH
R7220 95C0R3Q4S1510 J 150 1/16W Chip1608 AH
R7221 95C0R3Q4S1020 J 1k 1/16W Chip1608 AH
R7301 95C0R3Q4S2220 J 2.2k 1/16W Chip1608 AH
R7302 95C0R3Q4S2220 J 2.2k 1/16W Chip1608 AH
R7303 95C0R3Q4S1010 J 100 1/16W Chip1608 AH
R7304 95C0R3Q4S1020 J 1k 1/16W Chip1608 AH
R7305 95C0R3Q4S6820 J 6.8k 1/16W Chip1608 AH
R7306 95C0R3Q8S1820 J 1.8k 1/16W Chip1608 AC
R7307 95C0R3Q4S4710 J 470 1/16W Chip1608 AH
R7308 95C0R3Q8S2720 J 2.7k 1/16W Chip1608 AH
R7309 95C0R3Q8S1030 J 10k 1/16W Chip1608 AH
R7351 95C0R3Q4S2220 J 2.2k 1/16W Chip1608 AH
R7352 95C0R3Q4S8200 J 82 1/16W Chip1608 AH
R7353 95C0R3Q1V2710 J 270 1/8W Chip2012 AH
R7354 95C0R3Q8S1020 J 1k 1/16W Chip1608 AH
R7355 95C0R3Q8S4720 J 4.7k 1/16W Chip1608 AH
R7401 95C0R516FR050 J 0.05 3W AQ
R7402 95C0R516FR050 J 0.05 3W AQ
R7403 95C0R3Q8S2210 J 220 1/16W AH
R7404 95C0R3Q4S1030 J 10k 1/16W Chip1608 AH
R7405 95C0R3Q4S1030 J 10k 1/16W Chip1608 AH
R7406 95C0R3Q4S1020 J 1k 1/16W Chip1608 AH
