Sharp XV-Z12000 Service Manual

186
XV-Z12000
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
CPCi-A008CE01
PC I/F UNIT
INTEGRATED CIRCUITS
IC8001 RH-iX3270CEZZ J HD6417709(SH7709) BH
IC8002 9DK001-15061 J PST600IM AL
IC8003 9DK001-11045 J AT24C128N-10SJ-2.7 AS
IC8004 9DK001-15122 J PQ070XH02Z BC
IC8007 9DK001-12055 J TC7WH241FU AN
IC8008 9DK001-15147 J PQ050DZ01Z 5V1.0A AG
IC8011 9DK001-11046 J 24LC02B-I/SN AM
IC8019 9DK001-15060 J PST623XW AP
IC8025 RH-iXA091WJZZQ J CVIC2 BX
IC8027 RH-iXA823WJZZQ J LH28F320BFE AX
IC8028 9DK001-11027 J MSM51V18165F-60TS-K AX
IC8029 RH-iX3399CEN1 J IX3399CE BM
IC8052 9DK001-12089 J NC7ST08M5 AG
IC8053 9DK001-12057 J TC74LVX86FT AM
IC8298 VHiSii169G+-1Q J SiI169CTG BC
IC8302 9DK001-12107 J 74VHC153MTC AK
IC8306 9DK001-12070 J HD74HCT125T AL
IC8319 9DK001-15153 J BU4053BCFV AL
IC8320 9DK001-15153 J BU4053BCFV AL
IC8321 9DK001-15153 J BU4053BCFV AL
IC8322 9DK001-15153 J BU4053BCFV AL
IC8325 9DK001-12103 J 74LCX157MTC AK
IC8330 9DK001-15103 J CXA3516AR BQ
IC8331 9DK001-15103 J CXA3516AR BQ
IC8333 9DK001-12089 J NC7ST08M5 AG
IC8338 VHiVPC3230D1EQ J VPC3230D BD
IC8361 9KD001-11043 J HY57V643220CT-7 AY
IC8364 9DK001-15151 J PQ033DZ01Z 3.3V1.0A AG
IC8366 9DK001-12105 J 74LVX125MTC AK
IC8367 9DK001-15150 J LM319M AN
IC8368 9DK001-15152 J BU9831F AT
IC8369 9DK001-11049 J 24LC21A-/SN AN
IC8370 9DK001-15075 J SM5301AS BF
IC8371 9DK001-15089 J TL712CPW AR
TRANSISTOR
Q8012 9DK001-20039 J IMB3AF AE
Q8018 9DK001-20036 J NDC7002N AL
Q8019 9DK001-20041 J 2SC2412KF AC
Q8020 9DK001-20041 J 2SC2412KF AC
Q8021 9DK001-20041 J 2SC2412KF AC
Q8022 9DK001-20045 J HN1B04FU AL
Q8023 9DK001-20041 J 2SC2412KF AC
Q8024 9DK001-20041 J 2SC2412KF AC
DIODES
D8001 9DK001-30026 J MA3S137 AD
D8002 9DK001-30026 J MA3S137 AD
D8009 9DK001-30027 J 1SS355F AC
D8012 9DK001-30026 J MA3S137 AD
D8013 9DK001-30026 J MA3S137 AD
D8020 9DK001-30027 J 1SS355F AC
D8028 9DK001-30027 J 1SS355F AC
D8029 9DK001-30027 J 1SS355F AC
D8035 9DK001-30027 J 1SS355F AC
D8036 9DK001-30026 J MA3S137 AD
D8037 9DK001-30026 J MA3S137 AD
D8038 9DK001-30026 J MA3S137 AD
D8039 9DK001-30026 J MA3S137 AD
D8040 9DK001-30026 J MA3S137 AD
D8041 9DK001-30026 J MA3S137 AD
D8042 9DK001-30026 J MA3S137 AD
D8043 9DK001-30026 J MA3S137 AD
D8044 9DK001-30026 J MA3S137 AD
D8045 9DK001-30026 J MA3S137 AD
D8046 9DK001-30026 J MA3S137 AD
D8047 9DK001-30026 J MA3S137 AD
D8048 9DK001-30026 J MA3S137 AD
D8049 9DK001-30027 J 1SS355F AC
D8056 9DK001-30026 J MA3S137 AB
RDENCA055WJZZ
POWER UNIT(Continued)
R7407 95C0R3Q4S2240 J 220k 1/16W Chip1608 AH
R7408 95C0R3Q4S1000 J 10 1/16W Chip1608 AH
R7409 95C0R3Q4S6800 J 68 1/16W Chip1608 AH
R7411 95C0R3Q4S1530 J 15k 1/16W Chip1608 AH
R7412 95C0R3Q4S8220 J 8.2k 1/16W Chip1608 AH
R7413 95C0R3Q4S1030 J 10k 1/16W Chip1608 AH
R7414 95C0R3Q4S1030 J 10k 1/16W Chip1608 AH
R7415 95C0R3Q8S1530 J 15k 1/16W Chip1608 AH
R7416 95C0R3Q4S1030 J 10k 1/16W Chip1608 AH
R7417 95C0R3Q4S1030 J 10k 1/16W Chip1608 AH
R7418 95C0R3Q0V2730 J 27k 1/8W Chip2012 AH
R7419 95C0R3Q4S3910 J 390 1/16W Chip1608 AH
R7420 95C0R3Q4S1000 J 10 1/16W Chip1608 AH
R7421 95C0R3Q4S3910 J 390 1/16W Chip1608 AH
R7430 95C0R3Q8S2220 J 2.2k 1/16W Chip1608 AH
R7431 95C0R3Q8S8210 J 820 1/16W AH
å R7432 95C0R390T5640 J 560k 1/4W Chip3216 AH
å R7433 95C0R390T5640 J 560k 1/4W Chip3216 AH
å R7434 95C0R390T5640 J 560k 1/4W Chip3216 AH
MISCELLANEOUS PARTS
BEA7003 95C0W000A0050 J Jumper, 5mm AD
BEA7014 95C0L551A0010 J Ferrite Bead, AD
BL02RN1-R62 T2
BEA7202 95C0L551A0010 J Ferrite Bead, AD
BL02RN1-R62 T2
BEA7204 95C0L551A0010 J Ferrite Bead, AD
BL02RN1-R62 T2
CN7003 95C0WPF2004 J Connector AR
CN7101 95C0K202B0130 J Connector, B13B-PH-K-S AR
CN7102 95C0K202B0100 J Connector, B10B-PH-K-S AP
CN7103 95C0K202B0020 J Connector, B2B-PH-K-S AK
CN7104 95C0K206S0010 J Connector, AC-P07CN16 AT
CN7106 95C0K251A0020 J Connector, B2P3-VH AF
å F7001 95C0K718A6R30 J Fuse, AC250V 6.3AH 215 AN
å F7002 95C0K718A1R60 J Fuse, AC250V 1.6AH 215 AN
FH7001 95C0M850A0010 J Fuse Holder, TP00351-51 AK
FH7002 95C0M850A0010 J Fuse Holder, TP00351-51 AK
FH7003 95C0M850A0010 J Fuse Holder, TP00351-51 AK
FH7004 95C0M850A0010 J Fuse Holder, TP00351-51 AK
J7001 95C0W000A0070 J Jumper, 7.5mm AH
å RL7001 95CK3101AS001 J Relay, DJ5D2-0(M) TV-5 AZ
SHT7001 95C0PPS1020 J Sheet AQ
SHT7002 95C0PPS1020 J Sheet AQ
HS7001 95C0MPF0017 J Heat Sink AT
HS7003 95C0MPF0017 J Heat Sink AT
HS7004 95C0MPF0019 J Heat Sink AT
HS7101 95C0MPF0018 J Heat Sink AT
