No. Adjusting point Adjusting conditions Adjusting procedure
29
XV-Z12000
1. Make the following settings.
Destination Adjustment process Remote control setting
North America S4 Factory setting 4
Europe/Asia/
S3 Factory setting 3
Australia
16 Delivery set-
tings
15 Off-timer per-
formance check
1. Select OFF of LINE in the process mode and press
the ENTER key on the remote control.
The 5-minute display of the off timer appears and
check that the power is turned off about 6 seconds
after the display appears.
19 Thermistor
performance
check
1. Make sure that the temperature is indicated.
1. Heat the thermistor with a
hair dryer.
17 Auto sync
performance
check
1. Press the AUTO SYNC key on the remote control.
Check that the clock, phase, H-POS, V-POS can
be automatically adjusted.
1. Input the phase check pat-
tern of the VGA/S-VGA/
XGA signal to INPUT5.
No. Adjusting point Adjusting conditions Adjusting procedure
18 Inspection of
HTPC720P
Check that there is no abnormality with the screen.
To INPUT5 (DVI-I connector),
1. Input the color bar signal.
2. Input the gray scale signal.
3. Input the SMPTERP-133
signal.
1. Select the following group
and subject.
Group: SSS
Subject: S4
(North America)
S3 (Europe/
Asia/Australia)
1. Set to the no-signal state.
2. Select the following group
and subject.
Group: LINE
Subject: OFF
To Next Page
