XV-Z12000
Check the RGB input.
YES
NO
Is a projection image displayed?
Go to "Check the video input.".
NO
YES
Is the picture distorted?
Go to "Check the synchro-
nization signal.".
YES
NO
Are all three colors (R, G, and B)
being output?
Go to "Check the RGB signal.".
YES
NO
Is the image frame normal?
Go to "IC8004 peripheral
check".
End.
Select INPUT1 or INPUT2 using
the operation key or the remote
control.
Select INPUT1 or INPUT2 using
the operation key or the remote
control.
