Connecting the Projector to Other Devices
Using as a Wired Remote Control
Connecting the Remote
Control to the Projector
When the remote control cannot be used due
to the range or positioning of the projector (rear
projection, etc.), connect a ø3.5 mm minijack
cable (commercially available or available as
Sharp service part QCNWGA038WJPZ) from
the WIRED R/C JACK on the top of the remote
control to the WIRED REMOTE control input
terminal.
ø3.5 mm minijack cable
(commercially available or
available as Sharp service
part QCNWGA038WJPZ)
To WIRED R/C JACK
To WIRED REMOTE control
input terminal
-26
Remote control
