-24
Connecting the thumbscrew cables
■ Connect the thumbscrew cable making sure that it fits cor-
rectly into the terminal. Then, firmly secure the connec-
tors by tightening the screws on both sides of the plug.
■
Do not remove the ferrite core attached to the RGB cable.
Ferrite core
“Plug and Play” function
■ This projector is compatible with VESA-standard DDC 1/DDC 2B. The projector and a VESA DDC
compatible computer will communicate their setting requirements, allowing for quick and easy setup.
■ Before using the “Plug and Play” function, be sure to turn on the projector first and the con-
nected computer last.
Note
• The DDC “Plug and Play” function of this projector operates only when used in conjunction with a VESA
DDC compatible computer.
Connecting the Projector to Other Devices
XV_Z12000_E_US_p15_26.p65 03.9.26, 6:37 PM24
