Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
102
XV-Z2000
DT-400
DUNTKC753WEF0
MAIN UNIT (Continued)
IC5018 VHiTC7W74U/-1Y J TC7W74FU AD
IC5019 VHiHC1G32GW-1Y J 74HC1G32GW AD
IC6001 VHi7WH157FK-1Y J TC7WH157FK AF
IC6002 VHi7WH157FK-1Y J TC7WH157FK AF
IC6003 VHiTL712CPW-1Y J TL712CPWR AK
IC6004 VHiAD9883A1-1Q J AD9883AKST-110 BD
IC6005 VHiVCX257FT-1Y J TC74VCX257FT AG
IC6007 VHiMM3033D+-1Y J MM3033DURE AD
IC6008 VHiPQ1L333M-1Y J PQ1L333M2SP AD
IC6009 VHiTL712CPW-1Y J TL712CPWR AK
IC8002 VHiPST600iM-1Y J IC-PST600IMT AE
IC8004 VHiTC7W14U/-1Y J TC7W14FU AG
IC8006 VHiTC7W66U/-1Y J TC7W66FU AE
IC8201 VHiM62320FP-1Y J M62320FP AH
IC8202 RH-iXB196WJN1Q J IC AU
IC8203 VHiBR24L32F-1Y J BR24L32F-WE2 AG
IC8204 VHiPQ1L333M-1Y J PQ1L333M2SP AD
IC8205 VHiLB1831M/-1Y J LB1831M AL
IC8206 VHiLB1638M/-1Y J LB1638M-TE-R AL
Note: When replace the following parts, it becomes PWB
replacement correspondece.
IC8001 — – PW365-10U —
TRANSISTORS
Q501 VSHN1K03FU+-1Y J HN1K03FU AD
Q1701 VS2SC5384C/-1Y J 2SC5384C AB
Q2001 VS2SA1530AR-1Y J 2SA1530AR AB
Q2004 VS2SC3928AR-1Y J 2SC3928AR AB
Q2005 VS2SC3928AR-1Y J 2SC3928AR AB
Q2006 VS2SC3928AR-1Y J 2SC3928AR AB
Q2551 VSDTC114EE/-1Y J DTC114EE AB
Q2552 VSRN1702///-1Y J RN1702 AC
Q2553 VSRN1702///-1Y J RN1702 AC
Q3101 VS2SC3928AR-1Y J 2SC3928AR AB
Q3102 VS2SC3928AR-1Y J 2SC3928AR AB
Q3103 VS2SC3928AR-1Y J 2SC3928AR AB
Q3104 VS2SC3928AR-1Y J 2SC3928AR AB
Q3105 VS2SA1530AR-1Y J 2SA1530AR AB
Q3106 VS2SA1530AR-1Y J 2SA1530AR AB
Q3107 VS2SA1530AR-1Y J 2SA1530AR AB
Q3108 VS2SA1530AR-1Y J 2SA1530AR AB
Q3109 VS2SC3928AR-1Y J 2SC3928AR AB
Q3110 VS2SA1530AR-1Y J 2SA1530AR AB
Q3111 VS2SC3928AR-1Y J 2SC3928AR AB
Q3112 VS2SC3928AR-1Y J 2SC3928AR AB
Q3113 VS2SC3928AR-1Y J 2SC3928AR AB
Q3114 VS2SC3928AR-1Y J 2SC3928AR AB
Q3115 VSDTC114EE/-1Y J DTC114EE AB
Q3502 VS2SA1530AR-1Y J 2SA1530AR AB
Q3505 VS2SC3928AR-1Y J 2SC3928AR AB
Q3507 VS2SA1530AR-1Y J 2SA1530AR AB
Q3516 VS2SA1530AR-1Y J 2SA1530AR AB
Q3517 VS2SA1530AR-1Y J 2SA1530AR AB
Q5001 VSHN1B04FU/-1Y J HN1B04FU AC
Q5002 VS2SC3928AR-1Y J 2SC3928AR AB
Q6001 VSDTC114EE/-1Y J DTC114EE AB
Q8002 VSRN4904///-1Y J RN4904 AB
Q8003 VSHN1K03FU+-1Y J HN1K03FU AD
Q8006 VSRN4904///-1Y J RN4904 AB
Q8201 VSHN1B04FU/-1Y J HN1B04FU AC
DIODES
D503 VHDBAS316//-1Y J Diode AB
D504 VHDBAS316//-1Y J Diode AB
D505 VHDMA137///-1Y J Diode AC
D506 VHDMA137///-1Y J Diode AC
D507 VHDMA137///-1Y J Diode AC
D508 VHDMA137///-1Y J Diode AC
D509 VHDMA137///-1Y J Diode AC
D510 VHDMA137///-1Y J Diode AC
D511 VHDMA137///-1Y J Diode AC
D512 VHDMA137///-1Y J Diode AC
D1701 VHDBAS316//-1Y J Diode AB
D1702 VHDBAS316//-1Y J Diode AB
D1703 VHDBAS316//-1Y J Diode AB
D1704 VHDBAS316//-1Y J Diode AB
D1705 VHDBAS316//-1Y J Diode AB
D1706 VHDBAS316//-1Y J Diode AB
D1707 VHDBAS316//-1Y J Diode AB
D1708 VHDBAS316//-1Y J Diode AB
D1709 VHDBAS316//-1Y J Diode AB
D1710 VHD1PS184++-1Y J Diode AB
D1711 VHD1PS184++-1Y J Diode AB
D1712 VHDBAS316//-1Y J Diode AB
D1713 VHDBAS316//-1Y J Diode AB
D1714 VHDBAS316//-1Y J Diode AB
D1715 VHDBAS316//-1Y J Diode AB
D1716 VHDBAS316//-1Y J Diode AB
D1717 VHDBAS316//-1Y J Diode AB
D1718 VHDSFPA73//2EY J Diode AD
D1719 VHDSFPA73//2EY J Diode AD
D1720 RH-EX1230CEZZY J Zener Diode AB
D1721 RH-EXA087WJZZY J Zener Diode, 3.6V AB
D2001 RH-EXA087WJZZY J Zener Diode, 3.6V AB
D2003 RH-EXA087WJZZY J Zener Diode, 3.6V AB
D2004 RH-EXA087WJZZY J Zener Diode, 3.6V AB
D2005 RH-EXA092WJZZY J Zener Diode, 12V AB
D2006 RH-EXA092WJZZY J Zener Diode, 12V AB
D2007 RH-EXA092WJZZY J Zener Diode, 12V AB
D2008 RH-EXA092WJZZY J Zener Diode, 12V AB
D2009 RH-EX1393CEZZY J Zener Diode, 5.1V AB
D2010 RH-EXA087WJZZY J Zener Diode, 3.6V AB
D2011 RH-EXA087WJZZY J Zener Diode, 3.6V AB
D2551 RH-PX0210TAZZY J Power Indicator AC
D2552 RH-PX0210TAZZY J Lamp Indicator AC
D2553 RH-PX0196TAZZY J Temperature Warning AC
Indicator
D3101 VHD1PS226++-1Y J Diode AB
D3102 VHD1PS226++-1Y J Diode AB
D3103 VHD1PS226++-1Y J Diode AB
D3105 VHD1PS226++-1Y J Diode AB
D3106 VHD1PS226++-1Y J Diode AB
D3107 VHD1PS226++-1Y J Diode AB
D3108 VHD1PS226++-1Y J Diode AB
D3109 VHD1PS226++-1Y J Diode AB
D3110 VHD1PS226++-1Y J Diode AB
D3112 RH-EX1399CEZZY J Zener Diode, 9.1V AB
D3115 VHD1PS226++-1Y J Diode AB
D3116 VHD1PS226++-1Y J Diode AB
D3117 VHD1PS226++-1Y J Diode AB
D3501 RH-EX1399CEZZY J Zener Diode, 9.1V AB
D3502 RH-EX1399CEZZY J Zener Diode, 9.1V AB
D6001 RH-EX1394CEZZY J Zener Diode, 5.6V AB
D6002 RH-EX1394CEZZY J Zener Diode, 5.6V AB
D8201 VHDBAS316//-1Y J Diode AB
D8202 RH-EXA087WJZZY J Zener Diode, 3.6V AB
D8203 RH-EXA087WJZZY J Zener Diode, 3.6V AB
D8204 RH-EXA087WJZZY J Zener Diode, 3.6V AB
D8205 RH-EXA087WJZZY J Zener Diode, 3.6V AB
D8206 RH-EXA087WJZZY J Zener Diode, 3.6V AB
D8207 RH-EXA087WJZZY J Zener Diode, 3.6V AB
TH2002 RH-HXA001WJZZ J Thermister AD
PACKAGED CIRCUITS
X2001 RCRSC0141TAZZY J Crystal, 14.7456MHz AG
X3101 RCRSAA025WJZZ J Crystal, 16.2MHz AF
X8001 RCRUAA046WJZZY J Crystal, 74.25MHz AL
X8003 RCRUAA013WJZZY J Crystal, 133MHz AP
FILTERS AND COILS
FL510 RCiLFA051WJZZY J Filter Coil AH
FL511 RCiLFA051WJZZY J Filter Coil AH
FL512 RCiLFA051WJZZY J Filter Coil AH
FL513 RCiLFA051WJZZY J Filter Coil AH
FL3509 RCiLF0306CEZZY J Filter Coil AH
FL3510 RCiLFA034WJZZY J Filter Coil AE
