Sharp XV-Z2000 Service Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
103
XV-Z2000
DT-400
FL8001 RFiLNA071WJZZY J Noise Filter AD
L1701 RCiLPA213WJZZY J Peaking Coil AG
L1702 RCiLPA214WJZZY J Peaking Coil AG
L3104 VPCKM4R7JR88NY J Peaking 4.7µH AB
L3106 VPCKM4R7JR88NY J Peaking 4.7µH AB
L3107 VPCKM101J6R0NY J Peaking 100µH AB
L3502 VPCKM220J2R1NY J Peaking 22µH AB
L3505 VPCKM101J6R0NY J Peaking 100µH AB
L3506 VPCKM101J6R0NY J Peaking 100µH AB
L3507 VPCKM4R7JR88NY J Peaking 4.7µH AB
L3508 VPCKM220J2R1NY J Peaking 22µH AB
CAPACITORS
C501 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C502 RC-KZ0070TAZZY J 4.7 16V Ceramic AD
C503 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C504 VCEAPF1EW475MY J 4.7 25V Electrolytic AB
C505 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C506 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C507 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C508 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C509 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C510 VCEAPF0JW226MY J 22 6.3V Electrolytic AB
C511 VCKYCY1AB105KY J 1 10V Ceramic AB
C512 VCCCCY1HH101JY J 100p 50V Ceramic AA
C513 RC-KZA041WJZZY J 10 10V Ceramic AC
C514 RC-KZA041WJZZY J 10 10V Ceramic AC
C516 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C517 VCCCCY1HH181JY J 180p 50V Ceramic AA
C518 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C519 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C520 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C521 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C522 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C523 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C524 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C525 VCEAPF1CW106MY J 10 16V Electrolytic AB
C1701 VCEAPF0JW476MY J 47 6.3V Electrolytic AB
C1702 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1703 VCEAPF1CW107MY J 100 16V Electrolytic AC
C1704 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1705 VCEAPF1CW107MY J 100 16V Electrolytic AC
C1706 VCEAPF0JW476MY J 47 6.3V Electrolytic AB
C1707 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1708 VCEAPF1CW107MY J 100 16V Electrolytic AC
C1709 VCEAPF0JW476MY J 47 6.3V Electrolytic AB
C1710 VCEAPF0JW476MY J 47 6.3V Electrolytic AB
C1711 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1712 VCEAPF1CW107MY J 100 16V Electrolytic AC
C1713 VCEAPF1CW107MY J 100 16V Electrolytic AC
C1714 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1715 VCEAPF1CW107MY J 100 16V Electrolytic AC
C1716 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1717 RC-KZA070WJZZY J 22 6.3V Ceramic AD
C1718 VCEAPF1CW476MY J 47 16V Electrolytic AC
C1719 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1720 VCEAPF1CW476MY J 47 16V Electrolytic AC
C1721 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1722 VCEAPF1CW107MY J 100 16V Electrolytic AC
C1723 VCAAPD0JJ127MY J 120 6.3V Electrolytic AF
C1724 VCEAPF1CW476MY J 47 16V Electrolytic AC
C1725 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1726 VCEAPF1CW476MY J 47 16V Electrolytic AC
C1727 VCEAPF1CW476MY J 47 16V Electrolytic AC
C1728 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1729 VCEAPF1CW476MY J 47 16V Electrolytic AC
C1730 VCEAPF0JW226MY J 22 6.3V Electrolytic AB
C1731 VCKYCY1AB105KY J 1 10V Ceramic AB
C1732 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1733 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1734 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1735 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1736 RC-KZA070WJZZY J 22 6.3V Ceramic AD
C1739 VCEAPF1CW476MY J 47 16V Electrolytic AC
C1740 VCEAPF1CW476MY J 47 16V Electrolytic AC
C1741 VCEAPF1CW476MY J 47 16V Electrolytic AC
C1742 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1743 VCEAPF1CW476MY J 47 16V Electrolytic AC
C1744 VCKYCY1AB105KY J 1 10V Ceramic AB
C1746 VCKYCY1HB222KY J 2200p 50V Ceramic AA
C1748 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C1749 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C1750 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1751 VCAAPD1AJ686MY J 68 10V Electrolytic AE
C1752 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1753 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C1754 RC-KZA041WJZZY J 10 10V Ceramic AC
C1755 VCAAPD1AJ686MY J 68 10V Electrolytic AE
C1757 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1758 RC-KZA041WJZZY J 10 10V Ceramic AC
C1759 RC-KZA041WJZZY J 10 10V Ceramic AC
C1761 RC-KZA041WJZZY J 10 10V Ceramic AC
C2001 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2002 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2003 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2005 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2006 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2007 VCEAPF1CW106MY J 10 16V Electrolytic AB
C2008 VCCCCY1HH220JY J 22p 50V Ceramic AA
C2009 VCCCCY1HH220JY J 22p 50V Ceramic AA
C2010 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2011 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2012 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2013 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2014 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2015 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2016 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2017 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2018 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2019 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2020 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2023 VCEAPF1CW106MY J 10 16V Electrolytic AB
C3101 VCKYCY1AB105KY J 1 10V Ceramic AB
C3102 VCKYCY1AB105KY J 1 10V Ceramic AB
C3103 VCKYCY1AB105KY J 1 10V Ceramic AB
C3104 VCKYCY1AB105KY J 1 10V Ceramic AB
C3105 VCKYCY1AB105KY J 1 10V Ceramic AB
C3106 VCKYCY1AB105KY J 1 10V Ceramic AB
C3107 VCKYCY1AB105KY J 1 10V Ceramic AB
C3108 VCKYCY1AB105KY J 1 10V Ceramic AB
C3109 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3110 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3111 VCKYCY1AB105KY J 1 10V Ceramic AB
C3112 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C3113 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3114 VCEAPF1CW476MY J 47 16V Electrolytic AC
C3115 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3116 VCKYCY1AB105KY J 1 10V Ceramic AB
C3117 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3118 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3120 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3121 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3122 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3123 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3124 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3125 VCKYCY1AB105KY J 1 10V Ceramic AB
C3126 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3127 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3128 VCKYCY1AB105KY J 1 10V Ceramic AB
C3130 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3131 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3132 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3133 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3134 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3135 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3136 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
DUNTKC753WEF0
MAIN UNIT (Continued)

Sharp XV-Z2000 Specifications

General

Projection distance	2.6 - 3.9 m
Contrast ratio (typical)	2500:1
Screen size compatibility	40 - 200 \
Projector native resolution	SXGA (1280x1024)
Lamp type	SHP
Lamp power	275 W
Light source type	Lamp
Service life of light source	3000 h
Video in	XGA, Mac 19” (in intelligent compression), SVGA/VGA, Mac 16”/13”
I/O ports	2x component, 1x RCA video, 1x S-video, DVI-I (analogue component, digital & analogue RGB) x 1
Dimensions (WxDxH)	310 x 287 x 104 mm
Power requirements	100-240V AC, 50/60Hz
Power consumption (typical)	360 W
Market positioning	Home cinema

Weight and Dimensions

Weight	4300 g
