Sharp XV-Z2000 Service Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
106
XV-Z2000
DT-400
R1778 VRS-TX2HF2R2JY J 2.2 1/2W Metal Oxide AB
R1779 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R1780 VRN-CY1JF153DY J 15k 1/16W Metal Film AA
R1781 VRN-CY1JF432DY J 4.3k 1/16W Metal Film AA
R2002 VRS-CJ1JF103JY J 10k 1/16W Metal Oxide AA
R2003 VRS-CJ1JF103JY J 10k 1/16W Metal Oxide AA
R2004 VRN-CY1JF472DY J 4.7k 1/16W Metal Film AA
R2005 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2006 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2007 VRS-CH1JF102JY J 1k 1/16W Metal Oxide AA
R2008 VRS-CJ1JF100JY J 10 1/16W Metal Oxide AA
R2009 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2010 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2011 VRS-CY1JF100JY J 10 1/16W Metal Oxide AA
R2012 VRS-CJ1JF100JY J 10 1/16W Metal Oxide AA
R2015 VRS-CH1JF100JY J 10 1/16W Metal Oxide AA
R2017 VRS-CY1JF100JY J 10 1/16W Metal Oxide AA
R2018 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2019 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2020 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R2021 VRS-CH1JF102JY J 1k 1/16W Metal Oxide AA
R2022 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R2023 VRS-CH1JF103JY J 10k 1/16W Metal Oxide AA
R2025 VRS-CH1JF100JY J 10 1/16W Metal Oxide AA
R2026 VRS-CY1JF100JY J 10 1/16W Metal Oxide AA
R2027 VRN-CY1JF472DY J 4.7k 1/16W Metal Film AA
R2028 VRS-CY1JF100JY J 10 1/16W Metal Oxide AA
R2029 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2030 VRS-CJ1JF101JY J 100 1/16W Metal Oxide AA
R2031 VRS-CY1JF105JY J 1M 1/16W Metal Oxide AA
R2032 VRS-CH1JF103JY J 10k 1/16W Metal Oxide AA
R2033 VRS-CY1JF184JY J 180k 1/16W Metal Oxide AA
R2034 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2036 VRS-CJ1JF332JY J 3.3k 1/16W Metal Oxide AA
R2037 VRS-CJ1JF472JY J 4.7k 1/16W Metal Oxide AA
R2038 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2039 VRS-CJ1JF101JY J 100 1/16W Metal Oxide AA
R2040 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R2041 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R2042 VRS-CJ1JF100JY J 10 1/16W Metal Oxide AA
R2043 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2044 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2045 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2046 VRS-CY1JF184JY J 180k 1/16W Metal Oxide AA
R2049 VRS-CJ1JF472JY J 4.7k 1/16W Metal Oxide AA
R2050 VRS-CJ1JF101JY J 100 1/16W Metal Oxide AA
R2054 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2055 VRS-CY1JF822JY J 8.2k 1/16W Metal Oxide AA
R2056 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R2057 VRN-CY1JF273DY J 27k 1/16W Metal Film AB
R2058 VRS-CY1JF473FY J 47k 1/16W Metal Oxide AA
R2059 VRS-CY1JF473FY J 47k 1/16W Metal Oxide AA
R2060 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2551 VRS-TV1JD471JY J 470 1/10W Metal Oxide AA
R2552 VRS-TV1JD681JY J 680 1/10W Metal Oxide AA
R2553 VRS-TV1JD471JY J 470 1/10W Metal Oxide AA
R2554 VRS-TV1JD681JY J 680 1/10W Metal Oxide AA
R2555 VRS-TV1JD681JY J 680 1/10W Metal Oxide AA
R3101 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R3102 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R3103 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R3104 VRS-TV1JD000JY J 0 1/10W Metal Oxide AA
R3105 VRS-CY1JF331JY J 330 1/16W Metal Oxide AA
R3106 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R3108 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R3109 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R3111 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R3112 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R3113 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R3114 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R3115 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R3117 VRS-CY1JF473FY J 47k 1/16W Metal Oxide AA
R3118 VRS-CY1JF683JY J 68k 1/16W Metal Oxide AA
R3119 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R3120 VRS-CY1JF683JY J 68k 1/16W Metal Oxide AA
R3121 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R3122 VRS-CY1JF202JY J 2.0k 1/16W Metal Oxide AA
R3123 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R3124 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R3125 VRS-CY1JF683JY J 68k 1/16W Metal Oxide AA
R3126 VRS-CY1JF470JY J 47 1/16W Metal Oxide AA
R3127 VRS-CY1JF683JY J 68k 1/16W Metal Oxide AA
R3128 VRS-CY1JF683JY J 68k 1/16W Metal Oxide AA
R3129 VRS-CY1JF223FY J 22k 1/16W Metal Oxide AA
R3130 VRS-CY1JF683JY J 68k 1/16W Metal Oxide AA
R3131 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R3134 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R3136 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R3137 VRS-CY1JF470JY J 47 1/16W Metal Oxide AA
R3138 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R3139 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R3141 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R3142 VRS-CJ1JF103JY J 10k 1/16W Metal Oxide AA
R3143 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R3145 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R3146 VRS-CJ1JF472JY J 4.7k 1/16W Metal Oxide AA
R3148 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R3149 VRS-CJ1JF101JY J 100 1/16W Metal Oxide AA
R3153 VRS-CY1JF335JY J 3.3M 1/16W Metal Oxide AA
R3154 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R3155 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R3156 VRS-CY1JF470JY J 47 1/16W Metal Oxide AA
R3157 VRS-CY1JF560JY J 56 1/16W Metal Oxide AA
R3158 VRS-CY1JF682JY J 6.8k 1/16W Metal Oxide AA
R3160 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R3161 VRS-CY1JF470JY J 47 1/16W Metal Oxide AA
R3162 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R3163 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R3164 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R3165 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R3166 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R3167 VRS-CY1JF683JY J 68k 1/16W Metal Oxide AA
R3168 VRS-CY1JF683JY J 68k 1/16W Metal Oxide AA
R3169 VRS-CY1JF681JY J 680 1/16W Metal Oxide AA
R3170 VRS-CY1JF683JY J 68k 1/16W Metal Oxide AA
R3171 VRS-CY1JF273JY J 27k 1/16W Metal Oxide AA
R3172 VRS-CY1JF392JY J 3.9k 1/16W Metal Oxide AA
R3176 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R3177 VRS-CY1JF100JY J 10 1/16W Metal Oxide AA
R3179 VRS-CY1JF100JY J 10 1/16W Metal Oxide AA
R3181 VRS-CY1JF100JY J 10 1/16W Metal Oxide AA
R3183 VRS-CY1JF100JY J 10 1/16W Metal Oxide AA
R3185 VRS-CY1JF100JY J 10 1/16W Metal Oxide AA
R3186 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R3187 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R3189 VRS-CY1JF100JY J 10 1/16W Metal Oxide AA
R3190 VRS-CJ1JF101JY J 100 1/16W Metal Oxide AA
R3194 VRS-CY1JF683JY J 68k 1/16W Metal Oxide AA
R3195 VRS-CY1JF683JY J 68k 1/16W Metal Oxide AA
R3196 VRS-CY1JF683JY J 68k 1/16W Metal Oxide AA
R3207 VRS-CY1JF391JY J 390 1/16W Metal Oxide AA
R3208 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R3210 VRS-CY1JF391JY J 390 1/16W Metal Oxide AA
R3211 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R3213 VRS-CY1JF391JY J 390 1/16W Metal Oxide AA
R3214 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R3215 VRS-CY1JF221JY J 220 1/16W Metal Oxide AA
R3216 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R3501 VRS-TW2ED750JY J 75 1/4W Metal Oxide AA
R3505 VRS-TW2ED750JY J 75 1/4W Metal Oxide AA
R3506 VRS-TW2ED750JY J 75 1/4W Metal Oxide AA
R3507 VRS-CY1JF391FY J 390 1/16W Metal Oxide AA
R3509 VRS-CY1JF222FY J 2.2k 1/16W Metal Oxide AA
R3517 VRS-CY1JF182JY J 1.8k 1/16W Metal Oxide AA
R3522 VRS-CY1JF911JY J 910 1/16W Metal Oxide AB
R3525 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
DUNTKC753WEF0
MAIN UNIT (Continued)

Sharp XV-Z2000 Specifications

General

Projection distance	2.6 - 3.9 m
Contrast ratio (typical)	2500:1
Screen size compatibility	40 - 200 \
Projector native resolution	SXGA (1280x1024)
Lamp type	SHP
Lamp power	275 W
Light source type	Lamp
Service life of light source	3000 h
Video in	XGA, Mac 19” (in intelligent compression), SVGA/VGA, Mac 16”/13”
I/O ports	2x component, 1x RCA video, 1x S-video, DVI-I (analogue component, digital & analogue RGB) x 1
Dimensions (WxDxH)	310 x 287 x 104 mm
Power requirements	100-240V AC, 50/60Hz
Power consumption (typical)	360 W
Market positioning	Home cinema

Weight and Dimensions

Weight	4300 g
