Sharp XV-Z2000 Service Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
107
XV-Z2000
DT-400
R3526 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R3532 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R3537 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R3556 VRS-TX2HF2R2JY J 2.2 1/2W Metal Oxide AB
R3560 VRS-CY1JF821FY J 820 1/16W Metal Oxide AA
R3562 VRS-CY1JF471FY J 470 1/16W Metal Oxide AA
R3563 VRS-CY1JF181FY J 180 1/16W Metal Oxide AA
R3564 VRS-CY1JF122JY J 1.2k 1/16W Metal Oxide AA
R3565 VRS-CY1JF471FY J 470 1/16W Metal Oxide AA
R3569 VRS-CY1JF682JY J 6.8k 1/16W Metal Oxide AA
R3571 VRS-CY1JF392JY J 3.9k 1/16W Metal Oxide AA
R3576 VRS-CY1JF391JY J 390 1/16W Metal Oxide AA
R3577 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R3578 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R3579 VRS-CY1JF681JY J 680 1/16W Metal Oxide AA
R3580 VRS-CY1JF100JY J 10 1/16W Metal Oxide AA
R3583 VRS-CY1JF100JY J 10 1/16W Metal Oxide AA
R3585 VRS-CJ1JF101JY J 100 1/16W Metal Oxide AA
R3587 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R3590 VRS-CY1JF331JY J 330 1/16W Metal Oxide AA
R5001 VRS-CY1JF112FY J 1.1k 1/16W Metal Oxide AA
R5002 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R5003 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R5004 VRS-CY1JF392JY J 3.9k 1/16W Metal Oxide AA
R5005 VRS-CY1JF151FY J 150 1/16W Metal Oxide AA
R5006 VRS-CY1JF123JY J 12k 1/16W Metal Oxide AA
R5007 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R5008 VRS-CY1JF470JY J 47 1/16W Metal Oxide AA
R5009 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R5010 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R5011 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R5012 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R5015 VRS-CY1JF123FY J 12k 1/16W Metal Oxide AA
R5016 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R5017 VRS-CY1JF822FY J 8.2k 1/16W Metal Oxide AA
R5018 VRS-CY1JF392JY J 3.9k 1/16W Metal Oxide AA
R5019 VRS-CY1JF122JY J 1.2k 1/16W Metal Oxide AA
R5020 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R5025 VRN-CY1JF432DY J 4.3k 1/16W Metal Film AA
R5026 VRS-CY1JF182FY J 1.8k 1/16W Metal Oxide AA
R5028 VRS-CY1JF221JY J 220 1/16W Metal Oxide AA
R5029 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R5030 VRS-CY1JF683JY J 68k 1/16W Metal Oxide AA
R5047 VRS-CY1JF122JY J 1.2k 1/16W Metal Oxide AA
R5048 VRS-CJ1JF101JY J 100 1/16W Metal Oxide AA
R5051 VRS-CY1JF392FY J 3.9k 1/16W Metal Oxide AA
R5052 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R5054 VRS-CH1JF472JY J 4.7k 1/16W Metal Oxide AA
R5060 VRS-CY1JF470JY J 47 1/16W Metal Oxide AA
R5066 VRS-CY1JF152JY J 1.5k 1/16W Metal Oxide AA
R5067 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R6001 VRS-CY1JF271JY J 270 1/16W Metal Oxide AA
R6002 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R6003 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R6004 VRS-CY1JF392JY J 3.9k 1/16W Metal Oxide AA
R6005 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R6006 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R6007 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R6008 VRS-TV1JD000JY J 0 1/10W Metal Oxide AA
R6009 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R6010 VRS-CY1JF271JY J 270 1/16W Metal Oxide AA
R6011 VRS-CJ1JF101JY J 100 1/16W Metal Oxide AA
R6012 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R6013 VRS-CJ1JF470JY J 47 1/16W Metal Oxide AA
R6014 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R6015 VRS-CY1JF272JY J 2.7k 1/16W Metal Oxide AA
R6016 VRS-CH1JF470JY J 47 1/16W Metal Oxide AA
R6017 VRS-CH1JF470JY J 47 1/16W Metal Oxide AA
R6018 VRS-CY1JF392JY J 3.9k 1/16W Metal Oxide AA
R6019 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R6020 VRS-CH1JF470JY J 47 1/16W Metal Oxide AA
R6021 VRS-CH1JF470JY J 47 1/16W Metal Oxide AA
R6022 VRS-CH1JF470JY J 47 1/16W Metal Oxide AA
R6023 VRS-CH1JF470JY J 47 1/16W Metal Oxide AA
R6024 VRS-CH1JF470JY J 47 1/16W Metal Oxide AA
R6025 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R6026 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R6027 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R6028 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R6029 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R6030 VRS-CY1JF330JY J 33 1/16W Metal Oxide AA
R6043 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R6044 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R6057 VRS-TW2ED2R2JY J 2.2 1/4W Metal Oxide AA
R6058 VRS-TW2ED2R2JY J 2.2 1/4W Metal Oxide AA
R6059 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R6062 VRS-TV1JD000JY J 0 1/10W Metal Oxide AA
R6063 VRS-TV1JD000JY J 0 1/10W Metal Oxide AA
R8001 VRS-CH1JF332JY J 3.3k 1/16W Metal Oxide AA
R8004 VRS-CY1JF182JY J 1.8k 1/16W Metal Oxide AA
R8005 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R8007 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R8008 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R8011 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R8012 VRS-CH1JF470JY J 47 1/16W Metal Oxide AA
R8014 VRS-CH1JF470JY J 47 1/16W Metal Oxide AA
R8015 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R8018 VRS-CJ1JF000JY J 0 1/16W Metal Oxide AA
R8019 VRS-CH1JF332JY J 3.3k 1/16W Metal Oxide AA
R8021 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide AA
R8023 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R8027 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R8029 VRS-TV1JD000JY J 0 1/10W Metal Oxide AA
R8030 VRS-CH1JF220JY J 22 1/16W Metal Oxide AA
R8031 VRS-CH1JF220JY J 22 1/16W Metal Oxide AA
R8032 VRS-CH1JF220JY J 22 1/16W Metal Oxide AA
R8033 VRS-CH1JF220JY J 22 1/16W Metal Oxide AA
R8034 VRS-CH1JF220JY J 22 1/16W Metal Oxide AA
R8035 VRS-CH1JF220JY J 22 1/16W Metal Oxide AA
R8036 VRS-CH1JF220JY J 22 1/16W Metal Oxide AA
R8037 VRS-CH1JF220JY J 22 1/16W Metal Oxide AA
R8038 VRS-CH1JF220JY J 22 1/16W Metal Oxide AA
R8039 VRS-CH1JF220JY J 22 1/16W Metal Oxide AA
R8040 VRS-TV1JD000JY J 0 1/10W Metal Oxide AA
R8041 VRS-CH1JF220JY J 22 1/16W Metal Oxide AA
R8042 VRS-CH1JF220JY J 22 1/16W Metal Oxide AA
R8043 VRS-CH1JF220JY J 22 1/16W Metal Oxide AA
R8044 VRS-CH1JF220JY J 22 1/16W Metal Oxide AA
R8045 VRS-CY1JF470JY J 47 1/16W Metal Oxide AA
R8047 VRS-CY1JF220JY J 22 1/16W Metal Oxide AA
R8048 VRS-CH1JF220JY J 22 1/16W Metal Oxide AA
R8049 VRS-CH1JF220JY J 22 1/16W Metal Oxide AA
R8050 VRS-CH1JF220JY J 22 1/16W Metal Oxide AA
R8051 VRS-CH1JF220JY J 22 1/16W Metal Oxide AA
R8055 VRS-CH1JF220JY J 22 1/16W Metal Oxide AA
R8056 VRS-CH1JF220JY J 22 1/16W Metal Oxide AA
R8057 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide AA
R8060 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R8062 VRS-CY1JF470JY J 47 1/16W Metal Oxide AA
R8064 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R8065 VRS-CY1JF470JY J 47 1/16W Metal Oxide AA
R8067 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R8084 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R8086 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R8088 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R8089 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R8091 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide AA
R8201 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R8202 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R8203 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R8204 VRS-CY1JF332FY J 3.3k 1/16W Metal Oxide AA
R8205 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide AA
R8206 VRS-CJ1JF101JY J 100 1/16W Metal Oxide AA
R8208 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide AA
R8209 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R8211 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
DUNTKC753WEF0
MAIN UNIT (Continued)

Sharp XV-Z2000 Specifications

General

Projection distance	2.6 - 3.9 m
Contrast ratio (typical)	2500:1
Screen size compatibility	40 - 200 \
Projector native resolution	SXGA (1280x1024)
Lamp type	SHP
Lamp power	275 W
Light source type	Lamp
Service life of light source	3000 h
Video in	XGA, Mac 19” (in intelligent compression), SVGA/VGA, Mac 16”/13”
I/O ports	2x component, 1x RCA video, 1x S-video, DVI-I (analogue component, digital & analogue RGB) x 1
Dimensions (WxDxH)	310 x 287 x 104 mm
Power requirements	100-240V AC, 50/60Hz
Power consumption (typical)	360 W
Market positioning	Home cinema

Weight and Dimensions

Weight	4300 g
