Sharp XV-Z2000 Service Manual

38
XV-Z2000
DT-400
Adjustment by "Process
Menu"
→ "DLP" →
"INDEX". The failure state
remains unchanged.
Display in trouble
Screen with spectral
colors
Color production of R,
G and B is not correct.
Black screen
Are the sockets SC2001
and SC9001 connected
correctly?
Are the socket SC2001
and SC9001 connected
correctly?
Are the contact terminals
of the DMD, formatter
PWB and cLGA dirty?
Are the SC2001 and
SC9001 connected
correctly?
Does the color wheel
turn?
Does P9402 have the
correct motor drive
voltage waveform?
Is the waveform at pins
(18) and (20) of IC9202
the 400MHz sine wave?
IC9202, IC9101, X9101
or their peripheral
circuits are faulty.
Does the pin (3) of
IC9201 have the correct
voltage +1.8V?
Are the signals fed to the
terminating resistance
(39W) of RDRAM
(IC9203)?(DQA8 and
DQB8 are unused.)
Re-assemble the DMD,
the optical mechanism
and the formatter unit.
Do the colors return to
correct colors when the
process menu is
entered?
Poor adjustment should
be a likely cause.
Perform readjustment
according to the
adjustment method.
Color wheel is faulty.
IC2002 is faulty.
IC9401 or its peripheral
circuits are faulty.
Is the lamp lit on?
Check the color wheel
sensor unit.
IC2001, IC2007 or their
peripheral circuits are
faulty.
Is the correct voltage is
supplied to the each
connector of power and
ballast unit?
Check the ballast unit
and the power unit.
Does pin (2) of P2004
have 150Hz pulse signal
in no-signal state?
Does pin (9) of IC9301
have the correct voltage
(+23~+26V)?
Is pulse wave in voltage
at pin (14) of P1701?
IC9301 or its peripheral
circuits are faulty.
Miscellaneous
Equally spaced white or
black vertical stripes
Black horizontal band
IC9203, IC9101 or their
peripheral circuits are
faulty.
IC2007, IC2002 or their
peripheral circuits are
faulty.
Does pin (13) of IC9301
have the correct voltage
(-26V)?
Does pin (49) of IC9301
have the correct voltage
(+7V)?
Is the fan rotating?
Check the fan circuit.
Double-check DMD and
cLGA units.
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
NO
NO
NO
NO
NO
NO
NO
NO
NO
NO
NO
YES
» Formatter Unit Troubleshooting

Sharp XV-Z2000 Specifications

General

Projection distance	2.6 - 3.9 m
Contrast ratio (typical)	2500:1
Screen size compatibility	40 - 200 \
Projector native resolution	SXGA (1280x1024)
Lamp type	SHP
Lamp power	275 W
Light source type	Lamp
Service life of light source	3000 h
Video in	XGA, Mac 19” (in intelligent compression), SVGA/VGA, Mac 16”/13”
I/O ports	2x component, 1x RCA video, 1x S-video, DVI-I (analogue component, digital & analogue RGB) x 1
Dimensions (WxDxH)	310 x 287 x 104 mm
Power requirements	100-240V AC, 50/60Hz
Power consumption (typical)	360 W
Market positioning	Home cinema

Weight and Dimensions

Weight	4300 g
