Sharp XV-Z2000 Service Manual

44
XV-Z2000
DT-400
Checking the Sync Signal
Is the horizontal synchronized
signal on pin (6) of IC6003?
Is the vertical synchronized signal
on pin (6) of IC6009?
Is the synchronized signal
outputted from IC5009, IC5005,
IC5006, IC5007 and IC5008?
Are the timing of both vertical and
horizontal synchronized signals
correct?
Is the horizontal synchronized
signal on pin (30) of IC6004?
Is the vertical synchronized signal
on pin (31) of IC6004?
The sync signal is normal.
End of checking.
YES
NO
Check the of the signal input part.
NO
YES
YES
YES
YES
NO
YES
Check each IC and their peripheral
circuits.
NO
Check IC6001, IC6002 and their
peripheral circuits.
NO
Set the signal source appropriately.
NO
2
Is the signal generator (input
source) correct?
YES
IC8001 and its periphery is
defective.
NO
Is the horizontal synchronized
signal on pin (66) of IC6004?
Is the vertical synchronized signal
on pin (64) of IC6004?
YES
YES
NO
Failure of IC6004 and its
peripheral circuit.
NO

Sharp XV-Z2000 Specifications

General

Projection distance	2.6 - 3.9 m
Contrast ratio (typical)	2500:1
Screen size compatibility	40 - 200 \
Projector native resolution	SXGA (1280x1024)
Lamp type	SHP
Lamp power	275 W
Light source type	Lamp
Service life of light source	3000 h
Video in	XGA, Mac 19” (in intelligent compression), SVGA/VGA, Mac 16”/13”
I/O ports	2x component, 1x RCA video, 1x S-video, DVI-I (analogue component, digital & analogue RGB) x 1
Dimensions (WxDxH)	310 x 287 x 104 mm
Power requirements	100-240V AC, 50/60Hz
Power consumption (typical)	360 W
Market positioning	Home cinema

Weight and Dimensions

Weight	4300 g
