Sharp XV-Z2000 Service Manual

45
XV-Z2000
DT-400
Checking RS-232C
Communication is disabled even though
connecting the control PC and projector
with a RS-232C cable.
Is the connecting cable connected
correctly? (cross cable)
Replace the connecting cable.
Is there any signal at pin (8) of IC8002?
Check SC3501, R2039 and their peripheral circuits.
Is there any signal at pin (106) of IC2201? Check IC2006 and its peripheral circuits.
Check IC2002 and its peripheral circuits.
NO
YES
NO
YES
NO
YES

Sharp XV-Z2000 Specifications

General

Projection distance	2.6 - 3.9 m
Contrast ratio (typical)	2500:1
Screen size compatibility	40 - 200 \
Projector native resolution	SXGA (1280x1024)
Lamp type	SHP
Lamp power	275 W
Light source type	Lamp
Service life of light source	3000 h
Video in	XGA, Mac 19” (in intelligent compression), SVGA/VGA, Mac 16”/13”
I/O ports	2x component, 1x RCA video, 1x S-video, DVI-I (analogue component, digital & analogue RGB) x 1
Dimensions (WxDxH)	310 x 287 x 104 mm
Power requirements	100-240V AC, 50/60Hz
Power consumption (typical)	360 W
Market positioning	Home cinema

Weight and Dimensions

Weight	4300 g
