Shelly Wave Plug US User Manual

EN.
22
Supporting Command Class Basic
COMMAND_CLASS_BASIC is mapped into COMMAND_CLASS_SWITCH_BINARY, for enabling
Switch (O) control:
Switch (O) will be turned ON or OFF, after receiving the BASIC_SET command:
Basic Command received
Mapped Command (binary Switch)
Basic Set (0xFF)
Switch binary Switch (0xFF)
Basic Set (0x00)
Switch binary Switch (0x00)
Basic GET
Basic Report (Current Value, Target Value)
Supporting Command Class Indicator
The Device supports the Command Class Indicator V3 (ID 0x50). When the Device receives an
indicator set, the LED blinks according to the received indicator set.
Refer to LED Signalization chapter.
Supporting Meter Command Class
The Device supports the meter command class and KWh is the default scale report send when
the scale type is not present in the received Get.
Supported Scale Name
Scale Value
Watt
2
KWh
0
Volt
4
Ampere
5

Shelly Wave Plug US Specifications

General

Power supply	120 V ±10 %, 60 Hz
Power consumption	< 0.3 W
Power measurement [W]	Yes
Max switching voltage AC	140 V
Max switching current AC	15 A
Overheating protection	Yes
Overcurrent protection	Yes
Overvoltage protection	Yes
Distance	up to 40 m indoors (131 ft.) (Depends on local condition)
Shell material	Plastic
Color	White
Z-Wave repeater:	Yes
Z-Wave frequencies band(s)	908, 4
Maximum radio frequency power transmitted in frequency bend(s)	< 25 mW
CPU	Z-Wave S800
Compatible sockets	NEMA 5-15 (Type-B)
Compatible plugs	NEMA 1-15 (Type-A) and NEMA 5-15 (Type-B)
Ambient temperature	-20°C to 40°C / -5°F to 105°F
Humidity	30% to 70% RH
Max. altitude	2000 m / 6562 ft.

Weight and Dimensions

Size (H x W x D)	38x84x52 ±0.5 mm / 1.5x3.3x2.0 in ±0.02 in
Weight	70 ±1 g / 2.47 ±0.04 oz
