Shelly Wave Plug US User Manual

EN.
7
⚠CAUTION! Do not use the Device if it has been damaged!
⚠CAUTION! Do not attempt to service or repair the Device yourself!
⚠CAUTION! Connect the Device only in the way shown in these instructions. Any other method
could cause damage and/or injury.
⚠CAUTION! Do not allow children to play with the device, especially with the S button. Keep
the devices for remote control of Shelly Qubino (mobile phones, tablets, PCs) away from
children.
⚠CAUTION! The product is intended for indoor use only.
⚠CAUTION! Protect the product from dirt and moisture! Do not use the product in a damp
environment!
⚠CAUTION! Before cleaning the Device power off the connected appliance by pressing the S
button, unplug it and then unplug the Device itself. Never clean the Device, if it is connected to
the mains! Use a wet soft cloth to clean the Device.
⚠CAUTION! Do not use aggressive detergents!
⚠CAUTION! Do not immerse the Device or wash it under running water!
Insert Wave Plug US into a power socket without an appliance/load connected to it. Then you
can now plug an appliance into the Device socket. To power the appliance on press briefly the S
button. The LED will turn blue if load is between 0W and 85% of the max. power consumption
and red if load is >85% of the max. power consumption.
6. About Z-Wave®
The Z-Wave® protocol is an interoperable, wireless, RF-based communications technology
designed specifically for control, monitoring, and status reading applications in residential and
light commercial environments. Mature, proven, and broadly deployed, Z-Wave® is by far the
world market leader in wireless control, bringing affordable, reliable, and easy-to-use 'smart'
products to millions of people in every aspect of daily life.
Interoperability has always been at the core of the Z-Wave® protocol, alongside the features like
backward compatibility, security, and reliability. All Z-Wave® devices can be operated in any Z-
Wave® network with other Z-Wave® certified devices, regardless of brand or manufacturer. All
mains operated nodes within the network will act as repeaters regardless of vendor to increase
the reliability of the network. There are 4000+ Z-Wave certified products that are backwards-

Shelly Wave Plug US Specifications

General

Power supply	120 V ±10 %, 60 Hz
Power consumption	< 0.3 W
Power measurement [W]	Yes
Max switching voltage AC	140 V
Max switching current AC	15 A
Overheating protection	Yes
Overcurrent protection	Yes
Overvoltage protection	Yes
Distance	up to 40 m indoors (131 ft.) (Depends on local condition)
Shell material	Plastic
Color	White
Z-Wave repeater:	Yes
Z-Wave frequencies band(s)	908, 4
Maximum radio frequency power transmitted in frequency bend(s)	< 25 mW
CPU	Z-Wave S800
Compatible sockets	NEMA 5-15 (Type-B)
Compatible plugs	NEMA 1-15 (Type-A) and NEMA 5-15 (Type-B)
Ambient temperature	-20°C to 40°C / -5°F to 105°F
Humidity	30% to 70% RH
Max. altitude	2000 m / 6562 ft.

Weight and Dimensions

Size (H x W x D)	38x84x52 ±0.5 mm / 1.5x3.3x2.0 in ±0.02 in
Weight	70 ±1 g / 2.47 ±0.04 oz
