Shelly Wave Plug US User Manual

EN.
26
15. Technical Specifications
Power supply
120 V ±10 %, 60 Hz
Power consumption
< 0.3 W
Power measurement [W]
Yes
Max switching voltage AC
140 V
Max switching current AC
15 A
Overheating protection
Yes
Overcurrent protection
Yes
Overvoltage protection
Yes
Distance
up to 40 m indoors (131 ft.)
(Depends on local condition)
Z-Wave repeater:
Yes
CPU
Z-Wave S800
Z-Wave frequencies band(s)
908,4
Maximum radio frequency power
transmitted in frequency bend(s)
< 25 mW
Size (H x W x D)
38x84x52 ±0.5 mm / 1.5x3.3x2.0 in ±0.02 in
Weight
70 ±1 g / 2.47 ±0.04 oz
Compatible sockets
NEMA 5-15 (Type-B)
Compatible plugs
NEMA 1-15 (Type-A) and NEMA 5-15 (Type-B)
Shell material
Plastic
Color
White
Ambient temperature
-20°C to 40°C / -5°F to 105°F
Humidity
30% to 70% RH
Max. altitude
2000 m / 6562 ft.

Shelly Wave Plug US Specifications

General

Power supply	120 V ±10 %, 60 Hz
Power consumption	< 0.3 W
Power measurement [W]	Yes
Max switching voltage AC	140 V
Max switching current AC	15 A
Overheating protection	Yes
Overcurrent protection	Yes
Overvoltage protection	Yes
Distance	up to 40 m indoors (131 ft.) (Depends on local condition)
Shell material	Plastic
Color	White
Z-Wave repeater:	Yes
Z-Wave frequencies band(s)	908, 4
Maximum radio frequency power transmitted in frequency bend(s)	< 25 mW
CPU	Z-Wave S800
Compatible sockets	NEMA 5-15 (Type-B)
Compatible plugs	NEMA 1-15 (Type-A) and NEMA 5-15 (Type-B)
Ambient temperature	-20°C to 40°C / -5°F to 105°F
Humidity	30% to 70% RH
Max. altitude	2000 m / 6562 ft.

Weight and Dimensions

Size (H x W x D)	38x84x52 ±0.5 mm / 1.5x3.3x2.0 in ±0.02 in
Weight	70 ±1 g / 2.47 ±0.04 oz
