12.3 Overvoltage detected
Power
Management
Overvoltage
detected
Check the
RGB LED
signalization
table
Switch OFF
all outputs
and send a
notification
Any of the
following
activities reset
this alarm:
power cycle,
Remote Device
reboot (with
Parameter No.
117), short
press on the S
button, press on
any
switch/push-
button
connected to
any SW (SW,
SW1, SW2, …)
terminal.
YES
notification
type=power
management
Value=0x08,
event=State
Notification
name=Over-
voltage
detected
Value=0x07,
Version=V3
13. Z-Wave Associations
Associations are used for direct communication between the Device and other devices within
your Z-Wave network without the need of the Z-Wave gateway.
Max. number of associated devices per group is 9. This value is fixed and can not be configured.
Each association group supports the association of up to 9 devices (nodes). To avoid network
delays, we recommend limiting the number of associated devices to no more than 5 per group.
"Lifeline Group" is reserved for controlling devices, such as Gateways and remote controllers, or
devices who can interpret the reports sent.
Association group 1 - "Lifeline Group" sends to the controlling device it's command class
notifications and or command class reports when said command classes are triggered. Max. 9
nodes are allowed.

Shelly Wave Plug US Specifications

General

Power supply	120 V ±10 %, 60 Hz
Power consumption	< 0.3 W
Power measurement [W]	Yes
Max switching voltage AC	140 V
Max switching current AC	15 A
Overheating protection	Yes
Overcurrent protection	Yes
Overvoltage protection	Yes
Distance	up to 40 m indoors (131 ft.) (Depends on local condition)
Shell material	Plastic
Color	White
Z-Wave repeater:	Yes
Z-Wave frequencies band(s)	908, 4
Maximum radio frequency power transmitted in frequency bend(s)	< 25 mW
CPU	Z-Wave S800
Compatible sockets	NEMA 5-15 (Type-B)
Compatible plugs	NEMA 1-15 (Type-A) and NEMA 5-15 (Type-B)
Ambient temperature	-20°C to 40°C / -5°F to 105°F
Humidity	30% to 70% RH
Max. altitude	2000 m / 6562 ft.

Weight and Dimensions

Size (H x W x D)	38x84x52 ±0.5 mm / 1.5x3.3x2.0 in ±0.02 in
Weight	70 ±1 g / 2.47 ±0.04 oz
