36
• Depending on your speaker type, you can select one of these
following speaker types.
* Front, Center, Surround and Surround Back speakers :
L(Large): Select this when connecting speakers that can fully
reproduce sounds below crossover frequency.
S(Small) : Select this when connecting speakers that can not fully
reproduce sounds below crossover frequency. When
this is selected, sounds below crossover frequency are
sent to the subwoofer or speakers which are set to "L
(Large)" (when not using a subwoofer)
N(No): Select this when no speakers are connected. When this is
selected, sounds are sent to the speakers which are not
set to "N(No)".
* Surround Back speakers :
2/1 : Select the desired depending on the number of speakers
connected to SURROUND BACK/ROOM 2 terminals.
* Subwoofer :
Y(Yes)/N(No): Select the desired depending on whether a
subwoofer is connected or not.
■Notes :
• When speakers are set to "S (Small)", you should set their crossover frequency correctly according to their
frequency characteristics. (For details, refer to "When selecting the CROSSOVER" on page 38.)
• When "SUB-W" is set to "N (No)", "FRONT" is automatically set to "L (Large)".
• When the "FRONT" is set to "S (Small)", "CENTER", "SURR" and “SURR B” cannot be set to "L (Large)".
■About the speaker size
• Select "L (Large)" or "S (Small)" not according to the actual size of the speaker but according to the speaker's
capacity for playing low frequency (bass sound below frequency set on the "X-OVER" menu) signals.
• If you do not know, try comparing the sound at both settings (setting the volume to a level low enough so as not
to damage the speakers) to determine the proper setting.
3. Press the CURSOR LEFT(◀)/ RIGHT(▶) buttons to set the selected speaker as desired.
4. Repeat the above steps 2 and 3 until the speakers are all set to the desired mode.
2. Press the CURSOR UP(▲)/DOWN(▼) buttons to select the desired speaker.
ENGLISH
RD7405(A)100225_RD7405(A).qxp 2010-03-09 오전 9:47 페이지 36
