Wiring Diagram C
Shield Fire, Safety and Security Ltd.
Shield A-XT Releasing Fire Control Panel - Installation and Operation Manual SEXTCP-OM
Revision E01.00
93 of 127
A ground fault indication occurs when 30K Ohms or less exists
between earth-ground and the following field terminals of the
shield A-XT Releasing Fire Control Panel:
■ AUX24V
■ POWER, STATUS UNITS
■ NAC 1, NAC 2 and NAC 3
■ ZONE 1, ZONE 2, ZONE 3
■ MODE SELECT
■ MAN RELEASE
■ ABORT
■ REL. PRES. SWITCH
■ EXTING
■ LOWP. SWITCH
■ DATA, STATUS UNITS
