AUX 24V
Power Output Circuits
The Shield A-XT Releasing Fire Control Panel provides power output circuits on NAC 1, NAC 2, NAC 3, AUX
24V, STATUS UNITS, POWER and the EXTING terminals.
Reference Section 3, Installation for figures of the Notification Appliance Circuits and Status Units.
Remote Control Inputs
Remote Control Inputs are unused on the terminal-strip of the fire control panel:
Terminals Ratings
1st STAGE RELAY
(NC), (C) and (NO)
Power Factor: 1.0
Relay Function: Common
30 VDC @ 1A maximum, volt free change over contact
2nd STAGE RELAY
(NC), (C) and (NO)
Power Factor: 1.0
Relay Function: Common
30 VDC @ 1A maximum, volt free change over contact
EXTRACT
(NO) and (C)
Power Factor: 1.0
Relay Function: Common
30 VDC @ 1A maximum, volt free change over contact
Terminal Rating
AUX 24V (+ / R0V) 18 - 28 VDC Special Application Output, 500 mA maximum
Terminal Function
ROV No Connection (NC)
SIL NC
AL NC
FLT NC
RST NC
