Programming and Operating 4
Shield Fire, Safety and Security Ltd.
Shield A-XT Releasing Fire Control Panel - Installation and Operation Manual SEXTCP-OM
Revision E01.00
40 of 127
Configuration Codes
Not all configuration codes of the Shield A-XT Releasing Fire Control Panel are authorized for operation under
UL 864.
Reference Appendix G, UL 864 Permitted Configurations for the list of authorized configuration codes of the Shield
A-XT Releasing Fire Control Panel.
The table below describes configuration codes of Access Level 3:
Code Function Description
UXX Configuration update count Number increments each time Access Level 3 configuration changes.
Counter resets to 00 when 99 is reached.
C00 NAC delay time = 30 seconds Introduces a time delay before NACs operate. Only one delay period
can be selected. Delays are activated by the "Ad" option in Access
Level 2.
C01 NAC delay time = 1 seconds
C02 NAC delay time = 2 seconds
C03 NAC delay time = 3 seconds
C04 NAC delay time = 4 seconds
C05 NAC delay time = 5 seconds
C06 NAC delay time = 6 seconds
C07 NAC delay time = 7 seconds
C08 NAC delay time = 8 seconds
C09 NAC delay time = 9 seconds
C11 Zone 1 & Zone 2 detectors
trigger automatic release
Coincidence detection selection options. Only one option can be
selected.
C12 Zone 2 & Zone 3 detectors
trigger automatic release
C13 Zone 1 &Zone 3 detectors trigger
automatic release
C14 Zone 1 & Zone 2 OR Zone 2 &
Zone 3 OR Zone 1 & Zone 3
detectors trigger automatic
release
