Programming and Operating 4
Shield Fire, Safety and Security Ltd.
Shield A-XT Releasing Fire Control Panel - Installation and Operation Manual SEXTCP-OM
Revision E01.00
41 of 127
Code Function Description
C15 Zone 1 & Zone 2 & Zone 3
detectors trigger
automatic release
Coincidence detection selection options. Only one option can be
selected.
C16 Zone 1 OR Zone 2 OR Zone 3
detectors trigger automatic
release
C17 Zone 1 detectors trigger
automatic release
C18 Zone 2 detectors trigger
automatic release
C19 Zone 3 detectors trigger
automatic release
C21 Disable Fire Buzzer
C22 Disable Fire Output Fire Relay
C23 Disable Trouble Output Fire Relay
C24 Disable Earth Trouble Monitoring
C25 Pulse R0V Output
C26 Remove AUX 24V on system
reset
To enable resetting of system using AUX supply
C27 Indicate EXTING. released when
EXTING. output is active
Rather than upon receipt of signal from flow switch.
C28 No Activation delay upon manual
release
Delay remains active on automatic detection.
C29 Extinguishant output can be
reset during imminent phase.
Allows extinguishant output to be reset before countdown timer has
expired for installing and testing
