Operating the Fire Control Panel
Access levels are provided for controls and programming on the Shield A-XT Releasing Fire Control Panel.
Access Level 1 provides restricted controls, Access level 2 provides less restricted controls with limited programming
and Access Level 3 provides unrestricted controls and programming.
Access Level 2
To operate the Shield A-XT Releasing Fire Control Panel in Access Level 2:
Code Function Description
-00 No extinguishant delay Time delay between activation and extinguishant release output
operating. This menu option is accessed using the lamp test (+100)
button. The time is adjusted using the Mode button for 10’s and the
Select button for 5’s. Once the time is selected the Enter button is
used to store the value.
-05 5 second extinguishant delay
-10
TO
-55
Increment extinguishant delay in
five second steps
-60 60 second extinguishant delay
060 Sets extinguishant duration time
for 60 seconds
Time that extinguishant release output is activated. This menu option
is accessed using the lamp test (+100) button. The time is adjusted
using the Mode button for 10’s and the Select button for 5’s. Once the
time is selected the Enter button is used to store the value. Panel can
not be reset until this time has expired except by operating the
terminate extinguishant switch located under the front cover.
060
TO
295
Increment extinguishant duration
time in five second interval
300 Sets extinguishant duration time
for 300 seconds
1 Turn enable key-switch to get to access level 2.
2 Press Mode button until the required function is displayed in the System Mode LED.
3 Press the Select button to scroll to the required zone number then press Enter.
The “select dot” at the bottom of the System Mode LED flashes to confirm that the selected-function is active.
