Programming and Operating 4
Shield Fire, Safety and Security Ltd.
Shield A-XT Releasing Fire Control Panel - Installation and Operation Manual SEXTCP-OM
Revision E01.00
43 of 127
Code Function Description
C71 Zone 1 short circuit indicates
alarm
Changes the trigger threshold of the zone so that the fire control panel
can be used on older systems that do not have short circuit
monitoring. Any combination can be selected.
C72 Zone 2 short circuit indicates
alarm
C73 Zone 3 short circuit indicates
alarm
C81 Zone 1 non-latching Renders the zone self-resetting so that it can be used to receive
signals from other systems and resets when the input is removed. Any
combination can be selected.
C82 Zone 2 non-latching
C83 Zone 3 non-latching
CA1 Zone 1 device alarm must be
present for 30 seconds
Input delay. Any combination can be selected.
CA2 Zone 2 device alarm must be
present for 30 seconds
CA3 Zone 3 device alarm must be
present for 30 seconds
E00 Panel can be reset immediately
after discharge output has
operated
To allow reset of the panel to be prohibited before the extinguishant
discharge has fully completed.
E01
TO
E29
Panel can be reset 1 minute to
29 minutes after discharge
output has operated
E30 Panel can be reset 30 minutes
after discharge output has
operated
