Overview 2
Shield Fire, Safety and Security Ltd.
Shield A-XT Releasing Fire Control Panel - Installation and Operation Manual SEXTCP-OM
Revision E01.00
11 of 127
The table below describes upper controls of the Shield A-XT Releasing Fire Control Panel:
Central Controls
The figure below illustrates central controls of the Shield A-XT Releasing Fire Control Panel:
Figure 2-5
Central Controls
The table below describes central controls of the Shield A-XT Releasing Fire Control Panel:
Controls Modes
Releasing Key-Switch Provides key-switch modes for automatic & manual or manual-only release
Manual Extinguishant
Release
Provides manual release as a push button
Controls Modes
Silence/Sound Alarm
Re-sounds the alarm when NACs are silenced using the Silence Buzzer
button.
Silence Buzzer
Silences NACs connected to the Shield A-XT Releasing Fire Control Panel
after receiving authorization through Access Level 2.
Reset
Resets latching inputs such as fire and pre-alarm events after receiving
authorization through Access Level 2. Trouble events are non-latching inputs and
cannot be cleared by the Reset button. Non-latching inputs are cleared when
faults are cleared.
Lamp Test
Tests front-panel indicators and the internal buzzer by illuminating all LEDs while
darkening the front-panel display and sounding the buzzer.
Mode
Places the menu in a mode for operating or programming the Shield A-XT
Releasing Fire Control Panel.
Select
Selects the menu option displayed on the System Mode LED of the front-panel.
Enter
Enables the menu selection to function on the Shield A-XT Releasing Fire
Control Panel.
Enable Access
Places the menu of the Shield A-XT Releasing Fire Control Panel in
ACCESS LEVEL 2. Insert the key in the Enable Access lock and turn the key to
the right to open ACCESS LEVEL 2.
(+1)(+10)
Enter System ModeSelectModeReset Lamp Test
(+100)
Silence/Sound
Alarm
Silence
Buzzer
Enable Access
