Supplementary Devices 6
Shield Fire, Safety and Security Ltd.
Shield A-XT Releasing Fire Control Panel - Installation and Operation Manual SEXTCP-OM
Revision E01.00
57 of 127
The figure below illustrates Status Unit J2 jumper connections:
Figure 6-1
Status Unit - J2 Jumper Connections
The figure below illustrates an example of three Status Unit connections:
Figure 6-2
Example of Three Status Unit Connections
L
SWITCH
REL PRES. EXTING.ABORT
RELEASE
MAN.
SELECT
MODE2ND STAGE1ST STAGENAC3POWERDATA
STATUS UNITS
REMOTE
CONTROL
AUX
24V
NOCNCNOCNC
ZONE 3
E
ZONE 1 ZONE 2NAC2NAC1
RSTR0V SIL AL FLT
24V DC
FUSE
N
J2 Jumper
connected on
last Status Unit
J2 Jumper
removed from this
Ancillary Board
123
J2 Jumper
removed from
this Status Unit
Shield A-XT Releasing Fire Control Panel
ANCILLARY BOARD
To Next Page
