Front View, Wire Gauge and Related Documentation
of The Shield A-XT Releasing Fire control Panel
Wire Gauge
Connect 18 to 14 AWG wiring for all field terminations except the AC
input. Connect 14 AWG wiring for line, neutral and ground terminations
of the AC input.
Related Documentation
The following documents shall be used to provide additional information
for installing and operating the Shield A-XT Releasing Fire Control
Panel:
■ Installation and Operations Manual, SEXTCP-OM, Rev. E01.XX
■ Operating Instructions, SEXTCP-OI, Rev. P01.XX
■ UL Compliance Label, SEXTCP-UL, Rev. E01.XX
File: S8485, Part Number, SEXTCP-WR
Revision E01.00, Date: 5/1/2012
