Shimaden SRS10 Series User Manual

4
(1) Model code check
(SRS11 model code)
SRS11-8 Y Y-90-P 1 1 1 0
1. Series SRS11
2. Input 8: Multi-input, thermocouple, R.T.D., voltage (mV) 6: Voltage (V)
3. Control output 1 Y: Contact I: Current P: SSR drive voltage V: Voltage
4. Control output 2 N: None Y: Contact I: Current P: SSR drive voltage V: Voltage
EV3/DI4 E: Event output 1 point (EV3) D: External control input 1 point (DI4)
5. Power supply 90: 100-240V AC 08: 24V AC/DC
6. Programming function N: None P: With (4 patterns, max. 32 steps)
7. Event output 0: None 1: Event output 2 points (EV1, EV2)
8.
Analog output/communication 0: None 3: Voltage (0 ~ 10 mV) 4: Current (4 ~ 20 mA)
6: Voltage (0 ~ 10 V) 5: communication (RS-485)
9. DI/CT input 0: None 1:
CT 2 points input (Can be selected if control output 1 or 2 is Y, P)
2: External control input 3 points
10. Remarks 0: None 9: With
(SRS13/SRS14 model code)
SRS13-8 Y Y-90-P 1 4 1 2 5 0
1. Series SRS13 or SRS14
2. Input 8: Multi-input, thermocouple, R.T.D., voltage (mV) 6: Voltage (V)
3. Control output 1 Y: Contact I: Current P: SSR drive voltage V: Voltage
4. Control output 2 N: None Y: Contact I: Current P: SSR drive voltage V: Voltage
EV3/DI4 E: Event output 1 point (EV3) D: External control input 1 point (DI4)
5. Power supply 90: 100-240V AC 08: 24V AC/DC
6. Programming function N: None P: With (4 patterns, max. 32 steps)
7. Event output 0: None 1: Event output 2 points (EV1, EV2)
8. Analog output 0: None 3: Voltage (0 ~ 10 mV) 4: Current (4 ~ 20 mA) 6: Voltage (0 ~ 10 V)
9. CT input 0: None 1:
CT input 2 points (Can be selected if control output 1 or 2 is Y, P)
10. External control input 0: None 2: Control input 3 points (DI1, DI2, DI3)
11: Communication 0: None 5: RS-485
12. Remarks 0: None 9: With
(2) Accessories check
Instruction manual 1 copy
Communication interface instruction manual (if communication optional item added) 1 copy
Programming function instruction manual (if programming function optional item added) 1 copy
Unit seals 1 sheet
Note: Receiving impedance for current input (250Ω, 0.1%), current detector for heater break alarm (CT) and terminal cover
are sold separately as optional items and are not included with the controller.
Note: In the event you want to inquire about a product defect, missing accessory or other matter, please contact your
nearest Shimaden agent.
2-2. Notes on use
Do not press front panel keys with a hard or pointed object. Press lightly with your fingertips.
To clean, wipe lightly with a dry cloth. Do not use solvents such as thinner.
3. Installation and wiring
3-1. Installation site (environmental conditions)
 CAUTION
Environmental conditions for operations
The controller is designed to be used under the following
conditions. Observe the following environmental
conditions when using:
c
Must be used indoors
d
Max. elevation: 2000m
e
Ambient temperature: -10 to 50°C
f
Ambient humidity: Max. 90%RH, no condensation
g
Transient over voltage category: II
h
Pollution class: 2 (IEC 60664)
Do not use the controller in the following locations.
Doing so could lead to equipment failure, damage or fire.
* Places exposed to flammable or corrosive gases, oil mist, or
excessive dust that could cause insulation to deteriorate.
* Places subject to vibration or impact
* Places near strong electric circuit or places subject to inductive interference
* Places exposed to water dripping or direct sunlight
* Places where the controller is struck directly by air from heater or air
conditioner
