Shimadzu AOC-20 4 Using the control module
Sampler name
Assigns name to the sampler, under which it appears in configuration,
method setup, reports, etc.
Model
Defines the model of the AOC-20 sampler.
Vial size
Defines the type of the vials used on the sampler.
Syringe type
Defines the type of the syringe.
AOC-17 modeî
Setting this checkbox enables AOC-17 compatible mode.
To use the AOC20 in this mode, set the functions F84=1 (default is
F84=0).
Note: Regardless of mode used, the Channel 1 Protocol parameter must be
zero (F83=0).
Use three solvents
Defines whether the autosampler uses the three-vial solvent option or not.
When checked, additional options will be available on the Method Setup -
AS tab for selecting the solvent vials for pre-wash and post-wash.
- 11 -
