5 Maintenance and Inspections
5.3 Cleaning and Replacing the Quartz Cylinder
56 FPD-2010
3.
Remove
Remove this screw
FPD upper cover
the fixing screw show in figure 5.3.3 and remove the FPD upper cover.
Fig. 5.3.3　
