Shimadzu TOC-V - Outline; Chapter 3 Network Shared Settings

3 Network Shared Settings
3-1
3.1 Outline
This chapter explains The Shimadzu User Authentication Tool while picking up a setting
example in which the tool is shared in the LAN. In order to share the tool in the LAN, one
personal computer which acts as the database server is required. As the server database, the
SQL Server or the MSDE is required.
The MSDE is the database engine of the SQL Server offered by Microsoft free of charge. It is
customized for small-scale database systems.
Because each client personal computer refers to the database of the user authentication existing
in the server, the information can be unitarily controlled.
Server personal computer
Database
(SQL Server/MSDE)
The user authentication
is unitarily controlled
here, and logged in
through the server
personal computer.
Client personal computer
Ethernet
Client personal computer Client personal computer
