2.6.9 Parts List (SD-3000H)
Table 2-6：Parts List (SD-3000H)
No.
Description Part No. No.
Description Part No.
1 Front plate left - 16 Water flow regulator
-
2 Right lower door - 17 Return air pipe -
3 Right upper door - 18 Rear plate -
4 Star nut YW09675100000
19 Return air pipe -
5 Vacuum hopper cover 12l
YL21001200100
20 Air outlet pipe -
6 Circulation filter barrel lid - 21
Honeycomb
components
YW71965400100
7 Filter Adc3 ** YR50241400100
22 - -
8 Filter ** YR50277500000
23 Air inlet flange -
9 Installation box of filter - 24 Air outlet flange -
10 Circulation filter barrel - 25 - -
11 Outer rest - 26
High-pressure
blower 15HP*
YM30150300300
12 High-pressure blower 20HP *
YM30200300300
27 Dust screen ** YR40120300000
13 Heating case components* - 28 Exhaust fan ** YM60121200400
14 Cooler - 29 Electrical control box
-
15 Side plate - 30
Board of electric
components cabinet
-
* means possible broken parts.
** means easy broken part. and spare backup is suggested.
Please confirm the version of manual before placing the purchase order to guarantee that the
item number of the spare part is in accordance with the real object.
To Next Page
