Shini SD-H Series User Manual

40(83)
2.6.13 Parts List of Honeycomb (SD-700H/1000H/2000H/3000H)
Table 2-9：Parts List (SD-700H)
No. Description Part No. No. Description Part No.
1
4” Honeycom
flange
- 10 Flat washer 16 -
2
2.5” honeycomb
flange
- 11 Spring YW01201800000
3 Lower cover - 12 Hex nut M16 -
4 Honeycomb shaft - 13
Hexgon socket head
cap screw M8
-
5 Sychronous belt YR00305800000 14 Gear motor YM50512600000
6 Synchronous pulley YR00003000000 15 Belt adjustor -
7 Honeycomb YW71440400000 16
Mounting plate of gear
motor
-
8 Double-end screw BH10554500040 17 Locating tube -
9 Upper cover - 18 Synchronous pulley -
* means possible broken parts. ** means easy broken part. and spare backup is suggested.
Please confirm the version of manual before placing the purchase order to guarantee that the
item number of the spare part is in accordance with the real object.
Table 2-10：Parts List (SD-1000H/2000H)
No. Description Part No. No. Description Part No.
1
5” Honeycom
flange
- 10 Flat washer 16 -
2
3” honeycomb
flange
- 11 Spring YW01201800000
3 Lower cover - 12 Hex nut M16 -
4 Honeycomb shaft - 13
Hexgon socket head
cap screw M8
-
5 Sychronous belt YR00357300000 14 Gear motor YM10940000200
6 Synchronous pulley YR00003800000 15 Belt adjustor -
7 Honeycomb YW71554000100 16
Mounting plate of gear
motor
-
8 Double-end screw BH10554500040 17 Locating tube -
9 Upper cover - 18 Synchronous pulley -
* means possible broken parts. ** means easy broken part. and spare backup is suggested.
Please confirm the version of manual before placing the purchase order to guarantee that the
item number of the spare part is in accordance with the real object.
