Shini SD-H Series User Manual

64(83)
3.5 Cyclone Dust Collector
Picture 3-6：Installation Diagram of Cyclone Dust Collector
Cyclone Dust Collector Installation steps:
1. Connect 1 and 5 with a heat-resistant duct and fixed both the ends with
stainless steel tube.
2. Connect 2 and 3 with a heat-resistant duct and fixed both the ends with
stainless steel tube.
3. Connect 4 and 6 with a heat-resistant duct and fixed both the ends with
stainless steel tube.
3.6 Oil Filter
Picture 3-7：Installation Diagram of Oil Filter
