73(83)
4.11 Wrong Codes Remark
Table 4-2：Wrong Codes Remark
Wrong codes Remark
E-01 Break of temperature-sensed line
E-02 Inverse phase
E-03 Overload input
E-04 Overheat input for regen. EGO
E-05 Maximum temperature protection
E-07 Thermal protection temperature
E-08 Memory errors
E-09 Rotor Microswitch input
E-11 Reversed-phase of temperature sensed line
E-12 Auto-tuning errors
4.12 Installation for Dewpoint Monitor
1) Use blade to cut off the film and outline the reserved hole site on the SCD
control panel.
Picture 4-10：Hole Site
2) Check if there are complete parts for dewpoint monitor including:
Dew-point monitor
Dew-point transmitter assembly (dew-point detector, detection cable, washer
and installation guide)
To Next Page
