58(83)
2. Filter cleaning steps of EOP-30~500:
1) Open snap hook 4, take out tank cover 1, stainless steel filter 2 and activated
carbon filter 3.
2) Loose butterfly nut, take out stainless steel filter 2, and remove away dust
and oil from it by pressured air.
3) Loose butterfly nut, take out activated carbon filter 3 and replace activated
carbon.
4) Open oil storage bin 6, take out cooler 5 and remove away dust and oil from it
by pressured air.
5) Install oil filter after cleaning.
3. Filter cleaning steps of EOF-1000~4000:
1) Loose hexagon nut 1 and open material clearance door 4.
2) Loose hexagon nut 2, take out stainless steel filter 6 and middle efficient filter
5, remove away dust and oil from stainless steel filter and middle efficient
filter by pressured air.
3) Loose fixed nut 3, take out cooler 7 and remove away dust and oil from it by
pressured air.
4) Install oil filter after cleaning.
