VM-741 LOCAL COMMUNICATION &
PHASE MARKER MODULE
Page 2 of 4
VM-7 SERIES
SPECIFICATIONS
30909E1.2
Issued Feb. 2009
Revised Mar. 2010
Alarm contact operation
Monitor power ON
Monitor alarm relay mode Monitor power OFF
Normal state Alarm state
NO contact (NORMALLY DE-ENERGIZED) OPEN OPEN CLOSE
NO contact (NORMALLY ENERGIZED) OPEN CLOSE OPEN
NC contact (NORMALLY DE-ENERGIZED) CLOSE CLOSE OPEN
NC contact (NORMALLY ENERGIZED) CLOSE OPEN CLOSE
OTHERS
INPUT (PHASE MARKER)
Not used
SYSTEM-OK ALARM
Alarm reset : Auto Reset
Alarm contact mode : NORMALLY DE-ENERGIZED
Relay logic : “OR” of all OK alarm
COMMUNICATION
IP Adress : 192.168.8.8
Subnet mask : 255.255.255.0
IP Port No. : 8888
Default value
