Shinkawa VM-7 Series User Manual

Non-incendive *
1
Custom set up Tropical spec. Option *
2
(Developing)
1
Class I Division 2 CSA
*1 In future
VM-742 NETWORK COMMUNICATION
MODULE
Page 1 of 1
VM-7 SERIES
SPECIFICATIONS
ENVIRONMENTAL CONDITION
Operating temperature : 0 to +65°C
Storage temperature : –30 to +85°C
Relative humidity : 20 to 95%RH (noncondensing)
POWER CONSUMPTION
Module alone : Less than 15W
MATERIAL AND FINISH
Face plate : ABS(Black)
Sheet : Polyester tough top(Gray)
Base plate : Alminium alloy (Silver)
MASS
Body : Max. 1.0kg ( 2.21lb )
OTHERS
Note) The module is possible to install one or two module in a rack.
The module should be install to Slot.No.1 or Slot.No.2.
OUTPUT
Indicator : ACTIVE LED(Green)
When module is normal : Lighting
When module is abnormal : Off
Without attaching module to slot 1 or 2 : Flashing
COMM LED(Green)
When connecting communication : Lighting
When disconnecting communication : Off
When communicating : Flashing
NETWORK COMMUNICATION FUNCTION
Communication protocol : Modbus/TCP
Network standard : 10Base-T
Connector : RJ45 (Rear side of rack)
Communication
item : Data transmitted to host computer
Measurement value,GAP,Danger Alarm status,
Alert Alarm status,OK Alarm status,
Danger Bypass status,
Setting Value of Danger, Alert and OK Limit
Low-cut Filter(10pole) ON/OFF status,
Power-OK status,
Analyzed Data
*3
(0.5X amp./Phase,1X amp./Phase,
2X amp./Phase,Not-1X amp.)
: Data received from host computer
Date and Time Data
Option Communication item(
/CTR)
*2
: Data received from host computer
CH Bypass status,Danger Bypass status,
Low Alarm Bypass status,Alarm Reset,
Sequence Mode,Earthquake Filter,Peak Hold Reset,
Firstout Reset
Note)
*2 The control of VM-7 from host computer becomes possible by adding the option.
*3 When this module is added to the same Rack as VM-731 Analysis module, Analyzed Data
of the vibration channel from 3 to 8 Slot can be used.
Specification
VM-742 /NB1 /CSU /TRP /CTR
Default value
COMMUNICATION
Module ID : 1
IP Adress : 192.168.8.1
Subnet mask : 255.255.255.0
IP Port No. : 502
Timeout : Enable (10sec)
OTHERS
Model Code / Additional Spec. Code ( )
No entry if additional
spec, code is not specified.
30910E1.0
Issued Feb. 2009

Shinkawa VM-7 Series Specifications
