Mark VII Restored Manual - V1.02 – Donated without cost to the world-wide Shopsmith Community - Everett L. Davis 2016 61
PM2
46
507861
Duct (Includes Plug Cap)
PM2
47
501233
Clip - Blower
PM2
48
507195
Plug Cap - Duct
PM2
49
501502
Hose - Outlet (3 Ft. 8 In.)
PM2
50
501445
Adapter - Hose
PM2
51
9418403
Pin - Cotter (5/64 x 3/4)
PM2
52
501480
Ring - Retaining (1/2, Heavy Duty)
PM2
53
507757
Plate - Blower Housing
PM2
54
144811
• Screw - Sheet Metal (No. 10 x 1/2)
PM2
55
501234
Impeller
PM2
56
120394
• Washer (3/8 Nom.)
PM2
57
138489
• Lock-washer (3/8 Nom. Ext. Star)
PM2
58
102645
• Nut - Slotted (3/8 - 24)
PM2
59
501921
Clip - Duct
PM2
60
445132
• Nut - Tinnerman (No. 8, Flat Type
PM2
61
501238
Housing - Blower
PM2
62
501443
Hose - Inlet (5 Ft.)
PM2
63
507259
Nozzle - Utility
Mark VII Headstock Drive, Motor and Housing - PM4
PM4
1
504546
Spindle Assy. - Includes Bearing and Washer
PM4
2
504545
Quill
PM4
3
501622
Ring - Retaining (1-3/8, Internal)
PM4
4
501307
Ring - Bumper
PM4
5
102581
• Screw - Socket Set (5/18 - 18 x 3/8, Cup Point)
PM4
6
501306
Knob - Spindle
PM4
7
501624
Ring - Retaining (1-3/4, Inverted)
PM4
8
501294
Assembly - Drive and Ring
