3. View the Patching
Follow the below steps to view the patching:
01) Press <Patch> to enter Patch menu.
02) Press <E> [Patch Information] to view the patching info.
03) The button number, fixture name and address code will be displayed in the menu. Press < Up> or
<Down> to browse. Press the fixture button to go to the fixture directly.
4. Changing the DMX Address of a Fixture
You can re-patch a fixture to a different DMX address or a different DMX output line. All programming is
kept.
01) Press <Patch> to enter Patch menu.
02) Press <C> [Repatch Fixtures].
03) In the second line, the display shows the DMX address which is going to be used. You can change
this by turning the Wheel V. You can also use menu option A to patch onto the other DMX output
line.
04) Press the fixture button for fixture to patch that fixture at the new address.
05) Press <Enter> to confirm the change.
06) Repeat from step 3 if you want to change other fixture
If the new DMX address was already used, the fixture or dimmer on that fixture button will be
“parked”. All programming for the fixture button is preserved, but you need to patch it to a new DMX
address using the above procedure before you can use it again. If you view the fixture patch as
described above, the display will show “park.”
5. Deleting a Patched Fixture
01) Press <Patch> to enter Patch menu.
02) Press <Delete> to enter Delete Patch menu.
03) Press the fixture button, assigned to the fixture which you want to delete.
04) Press <Enter> to delete.
You can delete individual DMX channels from a fixture button by modifying the channel number
instead of pressing a fixture button. This is useful for deleting dimmer channels from fixture buttons
which have multiple channels patched to them. Be careful not to delete individual channels from
the fixtures using this function.
