14. Record/shift
This button can be used to enter record mode or
give you acces to the secondary (shift) functions of a
button.
15. Chase mode indicator
Indicates if the SC-2412 is in mix chase mode (orange
LED) or single chase mode (red LED).
16. Audio/page A-B button
Allows you to enter audio mode or switch between
page A or page B (in combination with the
record/shift (15) button).
17. Step button + LED
Allows you to step through a chase when the speed
fader is set in max position(completely down).
18. 5-10 min LED’s
Indicates if the SC-2412 is in mix or single mode.
19. Audio level fader
Allows you adjust the sensitivity for the built in
microphone or the audio input jack at the rear while
playing with audio triggering.
20. Speed fader
Allows you to adjust the speed for the scenes in program mode or in playback mode.
21. Fade fader
Allows you to adjust the fade time in playback mode.
22. Home button
Allows you to release a DMX channel which is in blind mode and return to normal chase playback. See
page 9: Blind (35) button.
23. Hold button
Allows you to toggle the hold mode on or off. The status of the hold mode is indicated by the green LED
above the button. Activating the hold mode during Chase playback, will hold a scene until you
deactivate the hold mode.
24. Tap sync button
Tapping this button allows you to sync the speed during chase playback.
25. Full on button
This button allows you to activate all 48 DMX channels at 100%.
26. Black out button
Push this button to kill all output.
27. LCD display
Shows the current activity or the programming state.
28. Down/beat rev button
This button allows you to modify a scene while in edit mode.
In combination with the record/shift (15) button, this button allows you to reverse the direction of a chase
while the chase is in audio control mode.
