Command String:
< SET PRESET nn >
Where nn is the preset number
1-10. (Leading zero is optional when
using the SET command).
MXA910 Response:
< REP PRESET nn >
Where nn is the preset number
01-10.
Get Preset Name
Command String:
< GET PRESET1 >
< GET PRESET2 >
< GET PRESET3 >
etc
Send one of these strings to the
MXA910.
MXA910 Response:
< REP PRESET1 {yyyyyyyyyyyyyyyyyyyyyyyyy} >
< REP PRESET2 {yyyyyyyyyyyyyyyyyyyyyyyyy} >
< REP PRESET3 {yyyyyyyyyyyyyyyyyyyyyyyyy} >
etc
Whereyyyyyyyyyyyyyyyyyyyyyyyyy
is 25 characters of the preset name.
The MXA910 always responds with
a 25 character preset name
Get Gate Out Status
Command String:
< GET x AUTOMIX_GATE_OUT_EXT_SIG >
Where x is ASCII channel number: 0
through 8. It is not necessary to con
tinually send this command. The
MXA910 will send a REPORT mes
sage whenever the status changes.
MXA910 Response:
< REP x AUTOMIX_GATE_OUT_EXT_SIG ON >
< REP x AUTOMIX_GATE_OUT_EXT_SIG OFF >
The MXA910 will respond with one
of these strings.
Get LED State
Command String:
< GET DEV_LED_IN_STATE >
