Step 11
Connect External Peripherals to Back-Panel
You are now ready to put the computer case back together and get on to the
external peripherals connections to your system's back-panel.
1. PS/2 Mouse and PS/2 Keyboard
2. LAN Port
3. USB1/2 Ports
4. Parallel Port
5. COM Port
6. VGA Port
7. Audio Line-Out /Line-In / Mic-In Ports
8. MIDI/GAME Port
foxconn
2
3
8
5
6
1
7
4
