- 64 -
Parallel Port IRQ
Use this item to assign IRQ to the parallel port.a port address.
Ø The choice: 7,5.
Parallel Port DMA
Use this item to assign a DMA channel to the parallel port.
Ø The choice: N/A.
OnBoard GAME Port
This item enables or disables the I/O address for the GAME Port.
Ø The choice: 201h,209h,Disabled.
OnBoard MIDI Port
Use this item to enable or disable the onboard MIDI port, and to assign a
port address.
MIDI Port IRQ
Use this item to assign IRQ 7 to the parallel port.
Ø The choice: 10,11,5.
OnBoard IDE
Use this item to enable or disable the onboard IDE channel.
Ø The choice: Both,Disabled,Primary or Secondary.
Audio Device
This item enables or disables the AC'97 audio chip.
Ø The choice: Enable or Disable.
Modem Device
This item enables or disables the MC'97 modem chip.
Ø The choice: Enable or Disable.
Ethernet Device
This item enables or disables the onboard Ethernet LAN.
Ø The choice: Enable or Disable.
USB Controller
Use this item to select the USB ports or disabled.
Ø The choice: Disabled, All USB Port, USB1, USB2, USB1&2,
USB3, USB1&3, USB2&3.
