Technical Information Chapter 4
CLV61x
Electrical installation
8015592/ZNI9/2017-06-13 © SICK AG · Germany · All rights reserved · Subject to change without notice 45
4.8.7 Wiring the "External input 1" Switching Input in the CDM420-0001 Connection
Module
+24 V* = DC 10 V to 30 V
V
in
= max. 32 V
CDM420-0001
CDM420-0001
PNP sensor
V
S
GND
Out
GND
S6
e.g. photo-electric
switch
V
S ext
CLV61xCDM420-0001
PNP sensor
V
S
GND
3.32 K
6.64 K
V
in
V
in
V
in
Out
GND
S6
e.g. photo-electric switch
CMC600
GND
S6
CMC600
CMC600
a) Sensor supplied by CDM420-0001
b) Sensor connected electrically isolated/externally supplied
d) Switch connected electrically isolated/externally supplied
c) Switch supplied by CDM420-0001
Connect the switch as shown in b)
Serial Aux
(RS-232)
Function assignment to "External input 1“ via SOPAS:
- Start of reading clock
- Stop of reading clock
- Start teach-in matchcode/start code comparison
- if required further functions in the future
Ratings for "External input 1"
("Aux In 1" switching input)
ON
OFF
S6 : SGND
No
YES
S8 : CMC
ON
OFF
S6 : SGND
No
YES
S8 : CMC
No
YES
S8 : CMC
ON
OFF
S6 : SGND
17
SGND
8
Shield
39
+24 V*
18
Aux In 1
17
SGND
8
Shield
39
+24 V*
18
Aux In 1
17
SGND
8
Shield
39
+24 V*
18
Aux In 1
+24V*
+24V*
+24V*
Software-controlled, the CMC600 transfers
the switching status of its physical "Aux In 1"
input automatically via the cable to the serial
Aux data interface of the CLV61x.
The CLV61x converts the status internally to
its logical "External input 1“.
"External
input 1"
Power fed to the input starts the
assigned function, e.g. start of
reading clock.
(default setting: logic not inverted
[active high], debouncing 10 ms)
– Optodecoupled, reverse polarity
protected
– Can be wired with the PNP output of
a sensor
– SensGND reference potential valid
for all switching inputs
Low: V
in
≤ 2 V; I
in
≤ 0.3 mA
High: 6 V ≤ V
in
≤ 32 V;
0.7 mA ≤ I
in
≤ 5 mA
Switching
behavior
Features
Electrical
values
Switch S6: SGND-GND
ON: GND of the sensor connected to GND
of CDB620/CMC600.
OFF: GND of the sensor connected to
SensGND of CDB620/CMC600
(Sensor connected electrically isolated
to the CDB620/CMC600).
Selected reference potential valid for all
switching inputs ("Sensor 1/2" and "In 1/2")
SensGND
SensGND
SensGND
