3 Product description
3.1 Product ID
3.1.1 Type label
The type label is attached on the housing side next to the electrical connections.
D-79276 Reute
Made in Germany
1
2
4
3
7
8
ß
9
à
CLV631-0831S01
P/N: 1062070
S/N: 1249 0007
DC 18...30V 8.5W
Imax=800mA
Pmax=1.5mW
P<1.0mW average
λ=655nm
Pulse duration <80μS
MAC 00:00:00:00:00:00
Manufactured: Dezember 2017
5
á
â
ã
6
Figure 4: Type label on IP69K protective housing (example)
1
Type designation according to type code
2
Part number
3
Serial number
4
Supply voltage and power consumption
5
Maximum current consumption
6
Maximum laser output
7
Average laser output
8
Laser wavelength
9
Laser pulse duration
ß
MAC address (only for Ethernet variant)
à
Production date
á
Data Matrix code with product data: Part number, production date, serial number, MAC
address for device, MAC address for Ethernet port (not shown on type label)
â
Symbol for protection class III
ã
Manufacturer and production site
Additional label
In addition to the type label, the additional label also displays other conformity marks
and test marks. The label is attached on the side of the housing with the electrical
connections, next to the type label.
25
3 PRODUCT DESCRIPTION
12
T E C H N I C A L I N F O R M A T I O N | CLV62x, CLV63x and CLV64x with IP69K Protective Housing 8021479/19ZB/2021-10-29 | SICK
Subject to change without notice
