7 Technical data
7.1 CLV62x bar code scanner in the IP69K protective housing
NOTE
The relevant online data sheet for your product including technical data and dimen‐
sions can be downloaded from the Internet: www.sick.com/CLV62x
Features
CLV620
Working range Mid range
Scanning methods Line scan or raster scan, type-dependent
Sensor type Line scanner or raster scanner
1)
, type-dependent, for identifier see type code in the operating
instructions
Orientation of viewing win‐
dow
On the front
Aperture angle ≤ 50°
Optical focus Fixed focus
Code resolution 0.2 mm ... 1.0 mm
Reading fields see "Reading fields", page 18 as well as the “Reading field diagrams (working ranges)” section
in the operating instructions
Scanning frequency 400 Hz … 1200 Hz
Light source Laser diode, visible red light (λ = 655 nm)
Light spot Circular
MTTF (laser diode) 40000 hours at 25 °C
MTBF 100,000 hours
Laser class Class 2 according to EN/IEC 60825-1: 2014. Identical laser class for issue EN/IEC 60825-1:
2007
Conforms to 21 CFR 1040.10 except for deviations per Laser Notice No. 50 of June 24, 2007,
and subsequent versions.
Laser power (maximum/aver‐
age)
1.5 mW / < 1.0 mW
Laser pulse duration < 300 μs
1)
Raster height approx. 15 mm at a reading distance of 200 mm.
Performance
CLV620
Readable code structures 1D codes
Bar code types Code 39, Code 128, Code 93, Codabar, GS1-128 / EAN 128, UPC / GTIN / EAN,
2/5 Interleaved, Pharmacode, GS1 DataBar, Telepen, MSI/Plessey
Print ratio 2:1 ... 3:1
No. of codes per scan 1 ... 20 (standard decoder)
1 ... 6 (SMART620)
No. of codes per reading
interval
1)
1 ... 50 (auto-discriminating)
No. of characters per code/
reading interval
Max. 50 characters Maximum 5,000 characters across all bar codes per reading interval, 500
characters for multiplexer function (CAN)
TECHNICAL DATA 7
8021479/19ZB/2021-10-29 | SICK T E C H N I C A L I N F O R M A T I O N | CLV62x, CLV63x and CLV64x with IP69K Protective Housing
31
Subject to change without notice
