CLV630 CLV631 CLV632
Protection class
(Class 3, EN 61140)
For operation in SELV systems (EN 60950-1) or ES1 systems (EN 62368-1)
Weight
2)
Front viewing window: 890 g, incl. double protective bushing
Side viewing window: 1230 g, incl. double protective bushing
Dimensions (L x W x H)
3)
Side viewing window: 85 mm x 84 mm x 154 mm
Side viewing window (oscillating mirror): 121 mm x 84 mm x 164 mm
Conformities CE.
For further conformities and certificates, see the product page on the Internet at:
www.sick.com/CLV63x
1)
For digital outputs without load.
2)
Without connecting cables.
3)
See also see "Design", page 13.
Ambient data
CLV630 CLV631 CLV632
EMC test Radiated emission: According to EN 61000-6-3: 2007-01
Shock resistance: According to EN 61000-6-2: 2005-08
Vibration resistance EN 60068-2-6: 2008-02
Shock resistance EN 60068-2-27: 2009-05
Ambient operating tempera‐
ture
0° C ... +40 °C
Storage temperature –20 °C ... +70 °C
Permissible relative humidity 0% ... 90%, non-condensing
Ambient light immunity 2000 lx, on bar code
Bar code print contrast (PCS) ≥ 60 %
7.3 CLV64x bar code scanner in the IP69K protective housing
NOTE
The relevant online data sheet for your product including technical data and dimen‐
sions can be downloaded from the Internet: www.sick.com/CLV64x
Features
CLV640
Working range Standard density
Scanning methods Line scan or raster scan, type-dependent
Sensor type Line scanner, raster scanner
1)
, or line scanner with oscillating mirror. For identifier, see the
type code in the operating instructions
Oscillating mirror functions
•
Fixed (adjustable position), oscillating (variable or fixed amplitude), one-shot
•
Oscillation frequency / period: 0.5 Hz ... 6.25 Hz / 2000 ms ... 160 ms
•
Angle of deflection: -20° ... +20° (adjustable using software)
Orientation of viewing win‐
dow
Front or side, for identifier see type code in operating instructions
Aperture angle ≤ 50°
Optical focus Dynamic focus adjustment
Code resolution 0.2 mm ... 1.0 mm (type-dependent)
Scanning frequency 400 Hz … 1200 Hz
7 TECHNICAL DATA
36
T E C H N I C A L I N F O R M A T I O N | CLV62x, CLV63x and CLV64x with IP69K Protective Housing 8021479/19ZB/2021-10-29 | SICK
Subject to change without notice
